130837 Festo Pneumatic Fittings

130837 on Powermatic Associates
Festo

Part#:130837

Alt. Part#:QSMLLV-M7-6-I

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

6 in stock

Apr 26, 2025

Product description

push-in L-fitting, long QSMLLV-M7-6-I 360° orientable, external thread with internal hexagon. Size: Mini, Nominal size: 1,9 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10

Product Details

  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Product weight
    12.4 g
  • Releasing ring color
    Blue
  • Material of tube retaining claw
    High-alloy stainless steel
  • Maritime classification
    See certificate
  • Design
    Push-pull principle
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Note on materials
    RoHS-compliant
  • Type code
    QSMLLV
  • Size
    Mini
  • Mounting position
    Any
  • Nominal width
    1.9 mm
  • Pack size
    10
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Ambient temperature
    -10 °C ... 80 °C
  • Nominal tightening torque
    3.35 Nm
  • Housing material
    PBT
  • Type of seal on screwed trunnion
    Sealing ring
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Pneumatic connection 1
    External thread M7
  • Releasing ring material
    POM
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Tolerance for nominal tightening torque
    ± 20%
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 6 mm
  • Material of tubing seal
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
