1254047 Festo Pneumatic Grippers

Product Details

• Rotational symmetry
  ≤ 0.2 mm
• Mode of operation
  Double-acting
• Position sensing
  For proximity sensor
• Min. opening time at 6 bar
  58 ms
• Maximum torque on gripper jaw, Mx static
  14 Nm
• Relubrication interval for guidance elements
  10 MioCyc
• Housing material
  Wrought aluminum alloy Hard-anodized
• Max. interchangeability
  ≤ 0.2 mm
• Pneumatic gripper repetition accuracy
  < 0.02 mm
• Gripper function
  Parallel
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Corrosion resistance class (CRC)
  1 - Low corrosion stress
• Type of mounting
  Optionally: Via through-hole and centering sleeve
• Cover cap material
  PA
• Size
  20
• Max. gripper jaw angular play ax, ay
  < 0.5 deg
• Number of gripper jaws
  2
• Design
  Lever Positively driven motion sequence
• Max. operating frequency of pneumatic gripper
  3 Hz
• Maximum force on gripper jaw Fz, static
  250 N
Product weight
387 g
Pneumatic connection
M5
Stroke per gripper jaw
6.5 mm
Type code
DHPS
Gripping force backup
On opening
Symbol
00995947
Min. closing time at 6 bar
97 ms
Mass moment of inertia
1.521 kgcm²
Maximum torque on gripper jaw, Mz static
14 Nm
Max. mass per external gripper finger
250 g
Gripper jaw material
High-alloy stainless steel
Max. gripper jaw backlash Sz
< 0.02 mm
Mounting position
Any
Guide
Sliding guide
Operating pressure
4 bar ... 8 bar
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Ambient temperature
5 °C ... 60 °C
Maximum torque on gripper jaw, My static
14 Nm
Note on materials
RoHS-compliant
