TTR713APSB6D-2.0FL-CTR Banner Safety Light Curtains

TTR713APSB6D-2.0FL-CTR on Powermatic Associates
Banner

Part#:TTR713APSB6D-2.0FL-CTR

Manufacturer:Banner

Category:Safety Light Curtains

Alt. Part#:809714

Product Lifecycle:Active

Get a quick Quote!

TTR Series 6 Beam Sensor Array 28.08 in Between Frame; Beam Spacing: 93.1 mm; Range: 120 mm Diffuse; Output: LO PNP; Input: 18-30 V dc; 2 m (6.5 ft) Flying Leads Endcap D: Flat Up / Round

About the manufacturer: Banner is one of the manufacturers that offers Safety Light Curtains that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the TTR713APSB6D-2.0FL-CTR Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    385.5532 g
  • Country Of Origin
    MX
  • Max Op. Relative Humidity (%)
    95% @ 55°C
  • Beam to Beam Spacing [mm]
    93.1
  • Distance to First Beam [mm]
    123.75
  • Number of Beams
    6
  • NEMA Rating
    N/A
  • Min Op. Temperature (°C)
    -10
  • IP Rating
    IP50
  • Indicator
    Indicator LEDs
  • Max Op. Temperature (°C)
    55
  • Lens Material
    Polycarbonate
  • Operation
    Light Operate
  • Output response time (ms)
    1
  • Delay at Power-up (ms)
    1500
  • Adjustments
    N/A
  • Number of Pins
    4
  • Power Supply/Supply Voltage
    18-30 V dc
  • Outputs
    PNP
  • Quick Disconnect Type
    No QD
  • Slot Overall Depth (mm)
    12
  • Max Sensing Range (mm)
    120
  • Connection
    Cable
  • Primary Housing Material
    Black Anodized Aluminum
  • Slot Depth/Array Length (mm)
    713
  • Housing Style
    Roller Conveyor
  • End Cap Type
    D: Hex Flat Up / Spring 8 mm Round
  • Sensing Mode (Detailed)
    Diffuse
  • Cable Length (m)
    2
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

TTR713APSB6D-2.0FL-CTR Description

Banner Engineering TTR713APSB6D-2.0FL-CTR is a sensor array designed with a diffuse mode featuring 6 beams. This part is pre-wired with a 2m cable that ends in bare flying leads, facilitating easy integration into various systems. It has a rectangular shape with an array length of 713mm and a beam spacing/pitch of 93.1mm. The sensor operates within a supply voltage range of 18Vdc to 30Vdc, with a nominal voltage of 24Vdc, and can function in ambient air temperatures ranging from -10 to +70°C. It offers a degree of protection rated at IP50, making it suitable for environments where dust protection is necessary. The sensor has a sensing distance of 120mm and utilizes infrared light with a wavelength of 940 nm for detection. It is equipped with one digital output (PNP transistor), allowing for straightforward signal processing.

Related documents TTR713APSB6D-2.0FL-CTR Specs

TTR713APSB6D-2.0FL-CTR 216696.pdf
