TTR381BMSB3T-2.0FL-CTR Banner Safety Light Curtains
Part#:TTR381BMSB3T-2.0FL-CTR
Alt. Part#:810318
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
TTR Series 3 Beam Sensor Array 15.0 in Between Frame; Beam Spacing: 93.1 mm; Range: 120 mm; Output: Bimodal; Input: 18-30 V dc; 2.0 m (6 ft) Flying Leads
Product Details
- Weight 299.37072 g
- Country Of Origin MX
- Lens Material Polycarbonate
- Beam to Beam Spacing [mm] 93.1
- Number of Beams 3
- Distance to First Beam [mm] 97.4
- NEMA Rating N/A
- IP Rating IP50
- Indicator Indicator LEDs
- Max Op. Relative Humidity (%) 95% @ 55°C
- Min Op. Temperature (°C) -10
- Max Op. Temperature (°C) 55
- Delay at Power-up (ms) 1500
- Special Feature: Remote Teach No
- Adjustments N/A
- Output response time (ms) 1
- Cable Length (m) 2
- Connection Cable
- Power Supply/Supply Voltage 18-30 V dc
- Number of Pins 4
- Slot Overall Depth (mm) 12
- Quick Disconnect Type No QD
- Outputs Bimodal
- Slot Depth/Array Length (mm) 375
- Housing Style Sensing Array Bar
- End Cap Type T: T-Slot Mounting
- Max Sensing Range (mm) 120
- Power DC
- Sensing Mode (Detailed) Diffuse
- Primary Housing Material Black Anodized Aluminum
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TTR381BMSB3T-2.0FL-CTR on Powermatic Associates is $158.00. Order now.
About the product
Banner Engineering TTR381BMSB3T-2.0FL-CTR is a sensor array designed with a diffuse mode featuring 3 beams. This part is pre-wired with a 2-meter cable that has bare end flying leads for connection. It has a rectangular shape with dimensions including a 381mm array length and a beam spacing/pitch of 93.1mm. The supply voltage required for operation ranges from 18Vdc to 30Vdc, with a nominal voltage of 24Vdc. It is designed to operate within an ambient air temperature range of -10 to +70 degrees Celsius. The sensor offers a degree of protection rated at IP50. It includes 1 digital output (PNP/NPN transistor) and has a sensing distance of 120mm. The light emitted by the sensor is in the infrared (IR) spectrum with a wavelength of 940 nm.
