TTR305BMSB3T-2.0FL-CTR Banner Safety Light Curtains
Part#:TTR305BMSB3T-2.0FL-CTR
Alt. Part#:810319
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
TTR Series 3 Beam Sensor Array 12.0 in Between Frame; Beam Spacing: 93.1 mm; Range: 120 mm; Output: Bimodal; Input: 18-30 V dc; 2.0 m (6 ft) Flying Leads
Product Details
- Weight 281.22704 g
- Country Of Origin MX
- Number of Beams 3
- Delay at Power-up (ms) 1500
- Adjustments N/A
- Lens Material Polycarbonate
- Slot Overall Depth (mm) 19
- Number of Pins 4
- Quick Disconnect Type No QD
- End Cap Type T: T-Slot Mounting
- Slot Depth/Array Length (mm) 299
- Connection Cable
- Outputs Bimodal
- Power Supply/Supply Voltage 18-30 V dc
- Housing Style Sensing Array Bar
- Cable Length (m) 2
- Sensing Mode (Detailed) Diffuse
- Max Sensing Range (mm) 120
- Power DC
- Primary Housing Material Black Anodized Aluminum
- Beam to Beam Spacing [mm] 93.1
- Max Op. Relative Humidity (%) 95% @ 55°C
- Distance to First Beam [mm] 59.4
- NEMA Rating N/A
- IP Rating IP50
- Max Op. Temperature (°C) 55
- Min Op. Temperature (°C) -10
- Indicator Indicator LEDs
- Special Feature: Remote Teach No
- Output response time (ms) 1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TTR305BMSB3T-2.0FL-CTR on Powermatic Associates is $158.00. Order now.
About the product
TTR Series 3 Beam Sensor Array 12.0 inch Between Frame, Beam Spacing: 93.1 mm Range: 120 mm, Output: Bimodal Input: 18 - 30 V dc, 2.0 m (6 ft) Flying Leads
