Q60VR3LAF1400 W-30 Banner Sensors & Transducers

Name: Q60VR3LAF1400 W-30
Brand: Banner

Q60VR3LAF1400 W-30 on Powermatic Associates

Part#:Q60VR3LAF1400 W-30

Manufacturer:Banner

Category:Sensors & Transducers

Product Lifecycle:Active

Product description

Adjustable-field class 1 Laser photo-electric sensor with background suppression system - Banner Engineering (Q series - Q60LAF) - Part #71891 - Sensing range 20cm...1.4m - Visible class 1 red Laser light - 1 x digital output (SPDT contact type) (Light-ON

Product Details

Primary brand
Banner Engineering
Supply voltage (AC)
24Vac-250Vac (200Vac / 220Vac / 240Vac nom.)
Sensing distance
20cm...1.4m
Operating mode
Light-ON Dark-ON
Material
thermoplastic housing Acrylic lns.
Net Height (mm)
75 mm
Product series / family name
Q series
Functions
Adjustable-field class 1 Laser photo-electric sensor green LED (power ON) yellow LED (output state) screw adjustment
Shape
Rectangular
Digital outputs
1 x digital output (SPDT contact type)
Ambient air temperature for operation
-10...+50 °C
Order code / Manufacturer SKU
71891
Main function
Sensor (Photo-electric)
Supply voltage (DC)
12Vdc-250Vdc (24Vdc / 48Vdc / 120Vdc nom.)
Light Color
Visible class 1 red Laser
Net Width (mm)
25 mm
Sub-range name
Q60LAF
Degree of protection
IP67 NEMA 6
Equivalent to
Q60VR3LAF1400W30
Net Depth (mm)
60 mm

Design

background suppression system

Connection type

Pre-wired with 30ft / 9m cable terminated with bare end flying leads

Response time

15ms / 0.015 s

Compliant with standard(s)

cURus CE

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Q60VR3LAF1400 W-30 Related Documents

Banner Engineering - Q60LAF Series - Datasheet.pdf
