PBFM1X43T5 on Powermatic Associates
Banner

Part#:PBFM1X43T5

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Fiber optic sensor with diffuse-reflective system - Bifurcated fiber - In-line sensing - Banner Engineering (Fiber sensors - Plastic fiber series) - Part #65902 - 1.5mm (end) diameter - 3ft / 1m length - Cylindrical (smooth) end tip shape - Stainless stee

Product Details

  • Fiber Sensing End Size - Mounting Area
    1.5 mm
  • Max Distance: DF-G1 (mm)
    No Data
  • Tariff Fiber Meters (fbm)
    4.06
  • Measured Max Distance (mm)
    No Data
  • Max Distance: DF-G2 (mm)
    No Data
  • Application: Liquid Level
    No
  • Termination Type
    Plastic Fiber Sensors
  • Feature: Small Object Detection
    No
  • Feature: Extended Range
    No
  • Application: Vacuum Feed Through
    None
  • Minimum Repeat Bending Endurance
    1000
  • Integrated Lens
    No
  • Termination
    Terminated
  • Minimum Bend Radius (mm)
    5
  • Sensing End Segment 1
    Ferrule
  • Retractile
    No
  • Fiber Optic Type
    Plastic
  • Fiber Sensing End Tip
    Ferrule
  • Sensing End Material (Specific)
    Stainless Steel
  • Max Distance: DF-G3 (mm)
    No Data
  • Feature: Chemical Resistant
    No
  • Max Temp ( °C)
    85
  • Core Diameter (mm)
    4 x 0.3
  • Flex Relief
    No
  • Fiber Sensing End Size
    1.5 mm
  • Fiber Length (m)
    1
  • Sensing Mode (General)
    Diffuse
  • Beam Exit
    In-line
  • Quantity Included
    1
  • Fiber Sheathing Material (Jacket)
    Polyethylene
  • Sensing Mode (Detailed)
    Reflective
  • Housing Style
    Round
  • Main function
    Fiber sensor
  • Shape
    Cylindrical (smooth) end tip
  • Order code / Manufacturer SKU
    65902
  • Product series / family name
    Fiber sensors
  • Material
    Stainless steel sensing end Plastic fiber Polyethylene fiber sheath
  • Sub-range name
    Plastic fiber series
  • Length
    3ft / 1m
  • Functions
    Fiber optic sensor
  • Ambient air temperature for operation
    +70 °C
  • Primary brand
    Banner Engineering
  • Design
    diffuse-reflective system Bifurcated fiber In-line sensing
  • Diameter
    1.5mm (end) 0.25mm fiber core

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
