Part#:PBCF21.7T

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Plastic Fiber, Diffuse Reflective, Core Dia.: 0.5 mm & 9 x 0.25 mm; Fiber Length 1.7 m, Coaxial, Ferrule, T Termination

Product Details

  • Max Distance: DF-G1 (mm)
    No Data
  • Max Distance: DF-G2 (mm)
    No Data
  • Max Distance: DF-G3 (mm)
    No Data
  • Measured Max Distance (mm)
    No Data
  • Fiber Sensing End Size - Mounting Area
    2.5 mm
  • Tariff Fiber Meters (fbm)
    5.63
  • Application: Liquid Level
    No
  • Termination Type
    Plastic Fiber Sensors
  • Application: Vacuum Feed Through
    None
  • Feature: Small Object Detection
    No
  • Feature: Extended Range
    No
  • Feature: Chemical Resistant
    No
  • Integrated Lens
    No
  • Minimum Repeat Bending Endurance
    5000
  • Max Temp ( °C)
    70
  • Termination
    Terminated
  • Sensing End Segment 2
    Probe
  • Minimum Bend Radius (mm)
    10
  • Core Diameter (mm)
    0.5
  • Flex Relief
    No
  • Retractile
    No
  • Sensing End Segment 1
    Ferrule
  • Fiber Length (m)
    0.5
  • Fiber Sensing End Size
    1.8 mm
  • Fiber Optic Type
    Plastic
  • Quantity Included
    1
  • Sensing Mode (General)
    Diffuse
  • Sensing End Material (Specific)
    Stainless Steel
  • Fiber Sensing End Tip
    Probe
  • Fiber Sheathing Material (Jacket)
    Polyethylene
  • Beam Exit
    In-line
  • Sensing Mode (Detailed)
    Coaxial
  • Housing Style
    Round

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
