K50UX2ARA Banner Ultrasonic Sensors

K50UX2ARA on Powermatic Associates
Banner
  • K50UX2ARA
  • K50UX2ARA

Part#:K50UX2ARA

Alt. Part#:804557

Manufacturer:Banner

Category:Ultrasonic Sensors

Product Lifecycle:Active

Product description

Ultrasonic Sensor 0.1 m to 1 m; Modbus Slave Device Via RS-485; Range: 100 mm - 1 m (3.94 in to 39.4 in); 230 mm (9 in) QD Cable

Product Details

  • Weight
    158.7572 g
  • Country Of Origin
    US
  • Feature: Chemical Resistant
    No
  • Power/Current Consumption (exclusive of load)
    11.3 mA @ 30 V dc
  • Max Operating Temperature (°C)
    70
  • Min Operating Temperature (°C)
    -40
  • Profibus
    No
  • Wireless
    Yes
  • RS-232
    No
  • Common Ethernet Protocol
    No
  • Application: Ultrasonic
    Yes
  • Supply Protection Circuitry
    Protected against reverse polarity and transient overvoltages
  • Max Op. Relative Humidity Non-Condensing (%)
    95 at 50°C
  • IP Rating
    IP67
  • Vibration
    MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
  • Temperature Effect (mm/°C)
    0.02% of sensing distance/°C
  • Delay at Power-up (ms)
    10000
  • Power Supply
    3.5-5.5 V dc / 10-30 V dc
  • Max Sensing Distance (mm)
    1000
  • Quick Disconnect Type
    M12 (Euro)
  • Primary Housing Material
    PBT
  • Sensing Mode (General)
    Proximity
  • Max Measurement Range
    >500 mm - <=1000 mm
  • Feature: Timing (Hold/Delay)
    No
  • PROFINET
    No
  • IO Link
    No
  • Feature: Clear Object Detection
    Yes
  • Barrel Diameter (mm)
    50
  • NEMA Rating
    NEMA 6
  • Ultrasonic Frequency (kHz)
    224
  • Output Protection
    Protected against short circuit conditions
  • Adjustments
    Software
  • Number of Pins
    5
  • Mechanical Shock
    IEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave
  • Minimum Sensing Distance (mm)
    100
  • Analog Resolution/Discrete Repeatability
    0.1% of distance (1.5 min)
  • Connection
    Pigtail QD
  • Indicator
    LED(s)
  • Input/Output
    Serial (Modbus)
  • Cable Length (m)
    0.23
  • PC Configurable
    No
  • Power
    DC
  • Device Type
    Sensor
  • Housing Style
    Barrel
  • 1-wire Serial Interface
    No
  • SSI
    No
  • RS-485
    Yes
  • RS-422
    No
  • Sensing Mode (Detailed)
    Time of Flight
  • Sensing Beam
    Ultrasonic

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of K50UX2ARA on Powermatic Associates is $384.00. Order now.

About the product

Banner Engineering K50UX2ARA is a wireless ultrasonic distance sensor belonging to the K50U series, designed with a time-of-flight system and a 1-wire serial interface for software adjustment. This sensor features an M50 cylindrical threaded/barrel shape with a thermoplastic housing, ensuring durability. It is pre-wired with a 6" / 150mm pigtail that terminates with a 5-pin Euro-style M12 connector for easy installation. The K50UX2ARA operates on a supply voltage of 3.5Vdc to 5.5Vdc, with a nominal voltage of 5Vdc, and can function within an ambient air temperature range of -40 to +70 degrees Celsius. It offers a degree of protection rated at IP67 and NEMA 6, making it suitable for challenging environments. The sensor has an M50 thread size and is capable of sensing distances from 30cm to 3m, utilizing a 114kHz transmission frequency for accurate distance measurement.

K50UX2ARA Related Documents
