IVURDM-QD-806RA Banner Cordsets
Product Details
- Weight 331.12216 g
- Country Of Origin TW
- Primary Orientation Straight
- Feature: Hazardous Area No
- Oil/Grease Resistant No
- Secondary AWG 24
- Secondary Orientation Right Angle
- Secondary Number of Conductors 8
- Primary AWG 24
- Secondary Coupling Method M12 Single Key
- Secondary Gender Male
- Secondary Connector Type EURO
- Primary Connector Type EURO
- Primary Number of Conductors 8
- Primary Gender Female
- Primary Coupling Method M12 Single Key
- Shield/No Shield Shield
- IP Rating IP67
- Voltage Rating (V) 30 V ac/dc
- Minimum Temp. (°C) -40
- Current Rating (A) 2.0
- Maximum Temp. (°C) 105
- Coupling Material/Color Nickel Plated Brass
- Shield Type Coupling
- Outside Cable Diameter (mm) 6.1
- Number of Connectors 2
- Trunk Length (m) No Trunk
- Cordset Length (m) 1.83
- Connector Body Material/Color PUR Black
- Cable Jacket Material PVC
- Cable Jacket Color Black
- Number of Contacts 8
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of IVURDM-QD-806RA on Powermatic Associates is $104.00. Order now.
About the product
Banner Engineering IVURDM-QD-806RA is a pre-assembled connecting/interconnect cable or cordset designed with double-ended connectivity. It features black PVC sheathing and measures 6ft (1.83m) in length. This part is equipped with an 8-pin Euro-style M12 male angled connector and an 8-pin Euro-style M12 straight female connector. It is rated for a voltage of 30Vac and 30Vdc, with a cable diameter of 6.1mm. The IVURDM-QD-806RA operates within an ambient air temperature range of -40 to +105°C and offers a degree of protection rated at IP67.
