PULS UB10.245 is an Uninterruptible Power Supply (UPS) control module from the UB-series, featuring an external battery with a 50% power reserve and a green status LED. This module is housed in aluminium and utilizes spring-clamp connections for its connections. It measures W49mm x H124mm x D117mm and operates on a supply voltage range of 22.5Vdc-30Vdc (24Vdc nominal). The rated current is 10A at 22.5Vdc with Output 1 providing 15A in normal mode and 10A/15A (360W) in buffer mode. Output 2 delivers 12V; 5A in both normal and buffer modes. Designed for DIN rail mounting, it can operate in ambient air temperatures ranging from -25 to +70°C. The current consumption is 1.1A at a 24Vdc input, and it is designed for DC networks. Visual position indicators include Ready, Buffering, Inhibit, and Replace Battery. It features protection functions against output overvoltage (32Vdc typical / 35Vdc max.) and overload/short-circuit current (min. 17.9A, max. 21A at load impedance). The output voltage is 22.5Vdc and 12Vdc (regulated) in buffer mode with a 23Vdc turn-ON. The efficiency is rated at 0.975 with a 24Vdc input, and the rated power is 360W (at 24Vdc) and 240W/360W in buffer mode. Power dissipation/losses are 3.4 W at no load and 6 W with a 10A output current at 24Vdc input. Ripple is 20mVpp (20Hz...20MHz; 50Ω), and electrical durability is rated at 114000 hours at 40°C with a 10A output and 24Vdc input, 148000 hours at 40°C with a 5A output and 24Vdc input, and 380000 hours at 25°C with a 10A output and 24Vdc input.
Quick Quote
PULS XT40.362 is a power supply unit part of the X-series, designed to convert AC to DC power with a semi-regulated 25% power reserve. It features a DC-OK relay contact output and operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 26.6A at 36Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.362 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 36 Vdc (1200W for typ. 15s with derating applicable from +60°C to +70°C), and includes protection functions such as output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 41.1V, has an efficiency of 0.955 (at 3x480Vac input), a start-up delay of 350ms, and a rise time of 40ms (70ms with 27mF load capacitance) at nominal input. The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, a hold time of 2.6ms at 3x480Vdc input, and power dissipation/losses of 45.2W at full output load. Its electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 480Vdc input), with higher durability at reduced loads or temperatures. The output stage capacitance is 11100µF, and the ripple is 2000mVpp (20Hz...2KHz; 50Ω).
Quick Quote
PULS YR40.245 is a redundancy unit within the Y-series, designed for single-input redundancy module applications, featuring 1 x input and 1 x output with built-in decoupling MOSFETs suitable for 1+1 or N+1 redundancy configurations. It has ATEX approval for hot-swappable connectors and operates on a supply voltage range of 8.4Vdc to 36.4Vdc, with nominal voltages of 12Vdc and 24Vdc. The unit measures 46mm in width, 124mm in height, and 127mm in depth, and utilizes screw-clamp connections for secure installation. It is rated for a current of 40A at 28Vdc, with a derating to 1A at temperatures ranging from +60°C to +70°C. Designed for DIN rail mounting, it can operate in ambient air temperatures from -40°C to +70°C. The YR40.245 has a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 22A threshold at 6V. It supports both series and parallel operation for 1+1 and N+1 redundancy, ensuring continued operation through the use of two or more identical power supplies in parallel. The output voltage range is 12-28Vdc, with power dissipation/losses of 1.8W at 20A input and 6.2W at 40A input. Its electrical durability is rated at 557,000 hours at 40°C and 20A output, and 1,576,000 hours at 25°C and 40A output. The output stage capacitance is 320µF, with a ripple of 80mVpp at 1x20A and 150mVpp at 40A, across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS CP5.241-S2 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It offers a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S2 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3W and 8.2W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 1800µF. Electrical durability ranges from 96000 to 775000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and push-in spring connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms.
Quick Quote
PULS CP5.242 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac inputs. Efficiency rates are 0.943 at 230Vac input, 0.935 at 120Vac input, and 0.927 at 100Vac input. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.242 provides protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 1800 µF. Electrical durability ranges from 96,000 to 775,000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with an enhanced DC input and a 20% power reserve, featuring a DC-OK relay contact output and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and offers an adjustable output voltage of 24Vdc-28Vdc. The unit is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W, with a hold time of 35ms.
Quick Quote
Power Supply, 480W, AC 100-240V | DC 110-150V input, 1 phase, 24-28Vdc output, 20A, monitoring display
Quick Quote
PULS CP10.241-R1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 39mm. The unit consumes 1.14A at 230Vac input and full output, 2.17A at 120Vac input and full output, and 2.63A at 100Vac input and full output, with a peak inrush current of 11A at 230Vac input and 7A at 120Vac input. It features an IP20 degree of protection and achieves an efficiency of 0.947 at 230Vac input. The dimensions of the CP10.241-R1 are W39mm x H124mm x D117mm. It has a start-up delay time of 240-300ms for 100-230Vac input and a rise time of 30ms to 75ms depending on the load capacitance. The power supply unit includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or redundancy. It is equipped with a built-in MOSFET as a decoupling device to prevent a faulty unit from affecting others in the system. The unit can handle back-feeding loads up to 35V without malfunctioning. Power dissipation losses are 13.4W at 230Vac input and full output load. The output stage capacitance is 4400µF, and the electrical durability ranges from 47,000 to 531,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series and features spring-clamp connections, a supply voltage range of 85Vac-264Vac for AC and 88Vdc-180Vdc for DC, with a rated current of 12A at 48Vdc up to +45°C. The rated power is 288W at -25 to +45°C, and the output voltage is adjustable between 24Vdc and 25.4Vdc, with a hold time of 37ms at 120/230Vac input.
Quick Quote
DC/DC Converter, 200W, DC 110V input, 24-28Vdc output, 8.3A, railway applications
Quick Quote
Power Supply, 120W, AC 200-240V input, 1 phase, 24-28Vdc output, 5A, DC-OK relay contact
Quick Quote
SLS12034T SolaHD - SolaHD™ SL Series Single and Multi Output Power Supplies - PN SLS12034T
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| UB10.245 PULS UB10.245 is an Uninterruptible Power Supply (UPS) control module from the UB-series, featuring an external battery with a 50% power reserve and a green status LED. This module is housed in aluminium and utilizes spring-clamp connections for its connections. It measures W49mm x H124mm x D117mm and operates on a supply voltage range of 22.5Vdc-30Vdc (24Vdc nominal). The rated current is 10A at 22.5Vdc with Output 1 providing 15A in normal mode and 10A/15A (360W) in buffer mode. Output 2 delivers 12V; 5A in both normal and buffer modes. Designed for DIN rail mounting, it can operate in ambient air temperatures ranging from -25 to +70°C. The current consumption is 1.1A at a 24Vdc input, and it is designed for DC networks. Visual position indicators include Ready, Buffering, Inhibit, and Replace Battery. It features protection functions against output overvoltage (32Vdc typical / 35Vdc max.) and overload/short-circuit current (min. 17.9A, max. 21A at load impedance). The output voltage is 22.5Vdc and 12Vdc (regulated) in buffer mode with a 23Vdc turn-ON. The efficiency is rated at 0.975 with a 24Vdc input, and the rated power is 360W (at 24Vdc) and 240W/360W in buffer mode. Power dissipation/losses are 3.4 W at no load and 6 W with a 10A output current at 24Vdc input. Ripple is 20mVpp (20Hz...20MHz; 50Ω), and electrical durability is rated at 114000 hours at 40°C with a 10A output and 24Vdc input, 148000 hours at 40°C with a 5A output and 24Vdc input, and 380000 hours at 25°C with a 10A output and 24Vdc input. | Puls | Quick Quote | ||
| XT40.362 PULS XT40.362 is a power supply unit part of the X-series, designed to convert AC to DC power with a semi-regulated 25% power reserve. It features a DC-OK relay contact output and operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 26.6A at 36Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.362 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 36 Vdc (1200W for typ. 15s with derating applicable from +60°C to +70°C), and includes protection functions such as output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 41.1V, has an efficiency of 0.955 (at 3x480Vac input), a start-up delay of 350ms, and a rise time of 40ms (70ms with 27mF load capacitance) at nominal input. The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, a hold time of 2.6ms at 3x480Vdc input, and power dissipation/losses of 45.2W at full output load. Its electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 480Vdc input), with higher durability at reduced loads or temperatures. The output stage capacitance is 11100µF, and the ripple is 2000mVpp (20Hz...2KHz; 50Ω). | Puls | Quick Quote | ||
| YR40.245 PULS YR40.245 is a redundancy unit within the Y-series, designed for single-input redundancy module applications, featuring 1 x input and 1 x output with built-in decoupling MOSFETs suitable for 1+1 or N+1 redundancy configurations. It has ATEX approval for hot-swappable connectors and operates on a supply voltage range of 8.4Vdc to 36.4Vdc, with nominal voltages of 12Vdc and 24Vdc. The unit measures 46mm in width, 124mm in height, and 127mm in depth, and utilizes screw-clamp connections for secure installation. It is rated for a current of 40A at 28Vdc, with a derating to 1A at temperatures ranging from +60°C to +70°C. Designed for DIN rail mounting, it can operate in ambient air temperatures from -40°C to +70°C. The YR40.245 has a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 22A threshold at 6V. It supports both series and parallel operation for 1+1 and N+1 redundancy, ensuring continued operation through the use of two or more identical power supplies in parallel. The output voltage range is 12-28Vdc, with power dissipation/losses of 1.8W at 20A input and 6.2W at 40A input. Its electrical durability is rated at 557,000 hours at 40°C and 20A output, and 1,576,000 hours at 25°C and 40A output. The output stage capacitance is 320µF, with a ripple of 80mVpp at 1x20A and 150mVpp at 40A, across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| CP5.241-S2 PULS CP5.241-S2 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It offers a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S2 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3W and 8.2W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 1800µF. Electrical durability ranges from 96000 to 775000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and push-in spring connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms. | Puls | Quick Quote | ||
| CP5.242 PULS CP5.242 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac inputs. Efficiency rates are 0.943 at 230Vac input, 0.935 at 120Vac input, and 0.927 at 100Vac input. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.242 provides protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 1800 µF. Electrical durability ranges from 96,000 to 775,000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with an enhanced DC input and a 20% power reserve, featuring a DC-OK relay contact output and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and offers an adjustable output voltage of 24Vdc-28Vdc. The unit is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W, with a hold time of 35ms. | Puls | Quick Quote | ||
| CP20.248 Power Supply, 480W, AC 100-240V | DC 110-150V input, 1 phase, 24-28Vdc output, 20A, monitoring display | Puls | Quick Quote | ||
| CP10.241-R1 PULS CP10.241-R1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 39mm. The unit consumes 1.14A at 230Vac input and full output, 2.17A at 120Vac input and full output, and 2.63A at 100Vac input and full output, with a peak inrush current of 11A at 230Vac input and 7A at 120Vac input. It features an IP20 degree of protection and achieves an efficiency of 0.947 at 230Vac input. The dimensions of the CP10.241-R1 are W39mm x H124mm x D117mm. It has a start-up delay time of 240-300ms for 100-230Vac input and a rise time of 30ms to 75ms depending on the load capacitance. The power supply unit includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or redundancy. It is equipped with a built-in MOSFET as a decoupling device to prevent a faulty unit from affecting others in the system. The unit can handle back-feeding loads up to 35V without malfunctioning. Power dissipation losses are 13.4W at 230Vac input and full output load. The output stage capacitance is 4400µF, and the electrical durability ranges from 47,000 to 531,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series and features spring-clamp connections, a supply voltage range of 85Vac-264Vac for AC and 88Vdc-180Vdc for DC, with a rated current of 12A at 48Vdc up to +45°C. The rated power is 288W at -25 to +45°C, and the output voltage is adjustable between 24Vdc and 25.4Vdc, with a hold time of 37ms at 120/230Vac input. | Puls | Quick Quote | ||
| QS10.241-60 DC/DC Converter, 200W, DC 110V input, 24-28Vdc output, 8.3A, railway applications | Puls | Quick Quote | ||
| PIC120.242C Power Supply, 120W, AC 200-240V input, 1 phase, 24-28Vdc output, 5A, DC-OK relay contact | Puls | Quick Quote | ||
| SLS12034T SLS12034T SolaHD - SolaHD™ SL Series Single and Multi Output Power Supplies - PN SLS12034T | SolaHD | Quick Quote | ||
