PULS CS3.241 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C. The unit has a net width of 32mm and dimensions of W32mm x H124mm x D102mm. It features screw-clamp connections for secure installation and is capable of being powered by either a single-phase AC supply from 85Vac to 264Vac (with specific nominal voltages listed) or a DC supply from 88Vdc to 375Vdc. The CS3.241 delivers a rated current of 3.3A at 24Vdc and 2.7A at 28Vdc, with an adjustable output voltage range of 24Vdc to 28Vdc. It has a rated power of 80W and includes protection functions such as output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. The unit supports series or parallel operation for redundancy, ensuring higher system availability. It also features a DC-OK relay contact output, indicating the operational status. The power supply's efficiency varies with input voltage, achieving up to 0.898 at 230Vac input. It has a start-up delay of 95ms and a rise time that varies depending on the input and load capacitance. The CS3.241 is designed for electrical durability, with operational lifespans detailed for various conditions, and includes a capacitance of 1450µF at the output stage.
Quick Quote
PULS QS40.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and has ATEX approval. The unit provides a rated current of 40A at 24Vdc and 34.3A at 28Vdc, with screw-clamp connections for installation. It supports a supply voltage range of 85Vac-264Vac across various nominal voltages and frequencies, with specific turn-ON and shutdown voltages. Part of the Q-series, it measures 125mm in width, 124mm in height, and 127mm in depth, housed in aluminium. Designed for single-phase networks, it offers a rated power of 960W, extendable to 1440W for short-term applications, and an adjustable output voltage between 24Vdc and 28Vdc. The unit includes protection against overvoltage, with active input inrush current limitation and overload/short-circuit protection. It allows for series or parallel operation for increased output power, with specific conditions for back-feeding loads. The efficiency rates vary with input voltage, and it features specific current consumption, time delay, and hold time values. Power dissipation/losses are detailed alongside electrical durability metrics under various conditions. The output ripple is specified at 100mVpp, with an output stage capacitance of 10200µF.
Quick Quote
PULS PIC240.241D is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion capabilities. It operates within an ambient air temperature range of -25 to +70°C and includes a DC-OK relay contact output. The unit provides a rated current of 20A at 24Vdc, with screw-clamp connections for secure installation. It supports a supply voltage range of 85Vac to 264Vac across various nominal voltages from 100Vac to 240Vac at a frequency of 47-63Hz, featuring a 150Vac turn-ON voltage and a 130Vac shutdown voltage. The PIC-series part measures 59mm in width, 124mm in height, and 127mm in depth, housed in a polycarbonate casing. It is suitable for single-phase networks and offers a rated power of 480W, with an adjustable output voltage range of 24Vdc to 28Vdc. Protection functions include output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. The unit allows for series or parallel operation for increased output ampacity or redundancy, with a resistance to back-feeding loads up to 35V. Efficiency rates vary by input voltage, achieving up to 0.953 at 230Vac. It features a peak inrush current consumption of 48A at 230Vac, with a start-up delay of 420ms and a hold time of 27ms at both 230Vac and 120Vac inputs. Power dissipation losses are noted at 23.7W for 230Vac input under full load. The electrical durability spans up to 557,000 hours at 25°C with a 10A load on a 1AC 230Vac input. Ripple is maintained at 100mVpp across a 20Hz to 20MHz frequency range, with an output stage capacitance of 4300µF.
Quick Quote
PULS UC10.241 is an Uninterruptible Power Supply (UPS) control module within the UC-series, featuring a bfr. module design with capacitive storage, separated inputs and outputs, and a green status LED. This DC/DC UPS control module is encased in an aluminium housing and utilizes spring-clamp connections for connectivity. It measures W126mm x H124mm x D117mm and operates on a supply voltage range of 22.5Vdc to 30Vdc, with a nominal 24Vdc. The rated current is 15A, both nominal and bfr., and it is designed for DIN rail mounting. The UC10.241 can operate in ambient air temperatures ranging from -40 to +60°C and has a current consumption of 1.1A at a 24Vdc input. It supports a DC network type and features visual position indicators for Ready, Buffering, Inhibit, and PC-mode. Protection functions include output overvoltage protection with a typical 32Vdc and a maximum of 35Vdc, and overload/short-circuit protection with a minimum of 17.9A and a maximum of 21A at load impedance. Series or parallel operation is not supported. The output voltage is a fixed 24Vdc, with a turn-ON voltage of 23Vdc, and it boasts an efficiency of 0.978 at a 24Vdc input. The rated power is 360W at 24Vdc, with hold times of 16.5s at 10A and 9s at 15A. Power dissipation/losses are 2.9W at 0A output current and 4.6W at 10A output current, with a ripple of 30mVpp across 20Hz to 20MHz at 50Ω. Its electrical durability ranges from 324000 hours at 25°C and 10A output to 34000 hours at 55°C and 15A output. The capacitance of the output stage is 1500µF.
Quick Quote
PULS CS10.241 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for a single-phase network. It operates within an ambient air temperature range of -25 to +70°C and supports a supply voltage range of 85Vac-132Vac / 184Vac-264Vac with auto-selection, featuring an 80Vac turn-ON voltage and a 75Vac shutdown voltage. The unit provides an adjustable output voltage of 24Vdc-28Vdc, with a rated current of 12A at an ambient temperature of less than 45°C and 10A at less than 60°C for 24Vdc, and slightly different ratings for 28Vdc. It has a rated power of 288W at less than 45°C ambient temperature and 240W at less than 60°C. The CS10.241 exhibits a current consumption of 2.23A at 230Vac input for full 24Vdc output, with varying consumption rates at 120Vac and 100Vac inputs, and a peak inrush current of 10A across all input voltages. It features an efficiency of up to 0.916 depending on the input voltage, with dimensions of W60mm x H124mm x D117mm. The unit includes a time delay of 850ms for start-up and offers protection functions such as output overvoltage protection and overload/short-circuit current protection. It supports series/parallel operation for redundancy and is resistant to back-feeding loads up to 35V. The power dissipation/losses are specified for different input conditions, and the electrical durability varies with operating conditions, reaching up to 334000 hours at 25°C with a 5A output at 230Vac input. The output stage capacitance is 7000µF, and the ripple is maintained at 50mVpp. Connection is facilitated through screw-clamp connections, and the design includes a 20% power reserve with a DC-OK relay contact output.
Quick Quote
PULS PISA11.401 is a protection unit designed as a 4-channel protection module with 1 input and 4 outputs, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and adheres to NEC Class 2 design specifications. The rated current is 20A, distributed as 6A + 6A + 12A + 12A with a derating of 0.025A/+60°C to +70°C for each channel. It features screw-clamp connections for secure installation. As part of the PISA11-series, this unit has dimensions of W45mm x H75mm x D91mm and requires a supply voltage of 18Vdc to 30Vdc, with 24Vdc being typical and 21.4Vdc needed to turn on the outputs. The output voltage is adjustable between 24Vdc and 28Vdc. Protection functions include short-circuit protection with an 8ms shutdown time and current limitation with a 20.5A to 30A adjustable threshold. Power dissipation at full output load with a 24V input is 4.2W. The processing time for turn-on delay of output is 270ms, and the voltage drop across channels 1+2 and 3+4 is 178mV and 182mV, respectively. Electrical durability is rated at 171,000 hours at 40°C and 485,000 hours at 25°C for outputs of 2x3A and 2x5A.
Quick Quote
PULS PISA11.410 is a protection unit designed as a 4-channel protection module with 1 input and 4 outputs, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and is designed according to NEC Class 2 standards. The rated current is 14.8A at 24Vdc, with screw-clamp connections for secure installation. As part of the PISA11-series, it measures 45mm in width, 75mm in height, and 91mm in depth. The supply voltage requirement ranges from 18Vdc to 30Vdc, with a specific input voltage of 21.4Vdc needed to activate the outputs. The output voltage is adjustable between 24Vdc and 28Vdc. Protection functions include short-circuit protection with a 10ms shutdown time and current limitation with an adjustable threshold between 16.6A and 23.6A. Power dissipation at full output load with a 24V input is 1.6W. The processing time for turn-on delay of output is 270ms, and the voltage drop is 92mV at 24V and 81mV at 28V. Electrical durability is rated at 220,000 hours at 40°C with 4x1.9A output and 622,000 hours at 25°C with 4x1.9A output.
Quick Quote
PULS QS40.484 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. Connection is facilitated through screw-clamp connections, and it supports a supply voltage range of 180Vac to 264Vac, accommodating various nominal voltages within this range at a frequency of 47-63Hz. The QS40.484, part of the Q-series, measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase network operation and delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation to increase output power. Efficiency is rated at 0.95 with a 230Vac input, and the unit exhibits a peak current consumption of 18A. Start-up and rise times are specified as 750ms and 18-35ms respectively, with a hold time of 30ms at 230Vac input. Power dissipation losses are detailed for both 230Vac and 120Vac inputs, and the electrical durability spans from 65,000 to 345,000 hours under various conditions. Ripple is maintained at 150mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 3700µF.
Quick Quote
PULS QT20.361 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 13.3A at 36Vdc and 11.4A at 42Vdc, with a power derating from 12W at +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac across various nominal voltages (380Vac to 525Vac) at 47-63Hz, with a 3-phase input. The QT20.361, part of the Q-series, measures 65mm in width, 124mm in height, and 127mm in depth, housed in aluminium. It is designed for a 3-phase network, with a rated power of 480W at 36Vdc and 42Vdc, and can momentarily support up to 720W for 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with protection functions including output overvoltage protection and active input inrush current limiting. It allows for series or parallel operation for increased output power and is resistant to back-feeding loads up to 48V. The unit boasts an efficiency of up to 0.948, with a peak current consumption of 10A at inrush. It features a start-up delay of 290-350ms, a rise time of 30-40ms depending on load capacitance, and a hold time of 22ms. Power dissipation is 27.4W at full output load with a 3x480Vac input and 26.3W with a 3x400Vac input. Its electrical durability ranges from 48,000 to 250,000 hours, depending on operating conditions, with a ripple of 100mVpp and an output stage capacitance of 500µF.
Quick Quote
PULS SLD2.100 is a power supply unit featuring galvanic isolation and a DC-OK relay contact output. It serves as both an AC/DC power supply unit (PSU) and a DC/DC converter, equipped with screw-clamp connections for secure installation. The dimensions of this unit are W49mm x H124mm x D102mm, designed for DIN rail mounting, making it suitable for compact spaces. It operates with a supply voltage range of 18Vdc-36Vdc (24Vdc nominal) and delivers a rated current of 8A at 4.5Vdc with a power derating from +60°C to +70°C. The ambient air temperature for operation spans from 0 to +70 °C. The SLD2.100 consumes 2.9A at full 18Vdc output and 1.5A at full 36Vdc output, supporting both series and parallel operation. The output voltage is adjustable between 4.5-5.5Vdc, with an efficiency of 0.82 at 24Vdc input. This unit offers a rated power of 40W, a hold time of 10ms at 24Vdc input, and experiences power dissipation/losses of 8.5W at 24Vdc input with a full output load. Additionally, it features a 300ms start-up delay and maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| CS3.241 PULS CS3.241 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C. The unit has a net width of 32mm and dimensions of W32mm x H124mm x D102mm. It features screw-clamp connections for secure installation and is capable of being powered by either a single-phase AC supply from 85Vac to 264Vac (with specific nominal voltages listed) or a DC supply from 88Vdc to 375Vdc. The CS3.241 delivers a rated current of 3.3A at 24Vdc and 2.7A at 28Vdc, with an adjustable output voltage range of 24Vdc to 28Vdc. It has a rated power of 80W and includes protection functions such as output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. The unit supports series or parallel operation for redundancy, ensuring higher system availability. It also features a DC-OK relay contact output, indicating the operational status. The power supply's efficiency varies with input voltage, achieving up to 0.898 at 230Vac input. It has a start-up delay of 95ms and a rise time that varies depending on the input and load capacitance. The CS3.241 is designed for electrical durability, with operational lifespans detailed for various conditions, and includes a capacitance of 1450µF at the output stage. | Puls | $200.00 | Quick Quote | |
| QS40.241 PULS QS40.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and has ATEX approval. The unit provides a rated current of 40A at 24Vdc and 34.3A at 28Vdc, with screw-clamp connections for installation. It supports a supply voltage range of 85Vac-264Vac across various nominal voltages and frequencies, with specific turn-ON and shutdown voltages. Part of the Q-series, it measures 125mm in width, 124mm in height, and 127mm in depth, housed in aluminium. Designed for single-phase networks, it offers a rated power of 960W, extendable to 1440W for short-term applications, and an adjustable output voltage between 24Vdc and 28Vdc. The unit includes protection against overvoltage, with active input inrush current limitation and overload/short-circuit protection. It allows for series or parallel operation for increased output power, with specific conditions for back-feeding loads. The efficiency rates vary with input voltage, and it features specific current consumption, time delay, and hold time values. Power dissipation/losses are detailed alongside electrical durability metrics under various conditions. The output ripple is specified at 100mVpp, with an output stage capacitance of 10200µF. | Puls | $1,055.00 | Quick Quote | |
| PIC240.241D PULS PIC240.241D is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion capabilities. It operates within an ambient air temperature range of -25 to +70°C and includes a DC-OK relay contact output. The unit provides a rated current of 20A at 24Vdc, with screw-clamp connections for secure installation. It supports a supply voltage range of 85Vac to 264Vac across various nominal voltages from 100Vac to 240Vac at a frequency of 47-63Hz, featuring a 150Vac turn-ON voltage and a 130Vac shutdown voltage. The PIC-series part measures 59mm in width, 124mm in height, and 127mm in depth, housed in a polycarbonate casing. It is suitable for single-phase networks and offers a rated power of 480W, with an adjustable output voltage range of 24Vdc to 28Vdc. Protection functions include output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. The unit allows for series or parallel operation for increased output ampacity or redundancy, with a resistance to back-feeding loads up to 35V. Efficiency rates vary by input voltage, achieving up to 0.953 at 230Vac. It features a peak inrush current consumption of 48A at 230Vac, with a start-up delay of 420ms and a hold time of 27ms at both 230Vac and 120Vac inputs. Power dissipation losses are noted at 23.7W for 230Vac input under full load. The electrical durability spans up to 557,000 hours at 25°C with a 10A load on a 1AC 230Vac input. Ripple is maintained at 100mVpp across a 20Hz to 20MHz frequency range, with an output stage capacitance of 4300µF. | Puls | $265.00 | Quick Quote | |
| UC10.241 PULS UC10.241 is an Uninterruptible Power Supply (UPS) control module within the UC-series, featuring a bfr. module design with capacitive storage, separated inputs and outputs, and a green status LED. This DC/DC UPS control module is encased in an aluminium housing and utilizes spring-clamp connections for connectivity. It measures W126mm x H124mm x D117mm and operates on a supply voltage range of 22.5Vdc to 30Vdc, with a nominal 24Vdc. The rated current is 15A, both nominal and bfr., and it is designed for DIN rail mounting. The UC10.241 can operate in ambient air temperatures ranging from -40 to +60°C and has a current consumption of 1.1A at a 24Vdc input. It supports a DC network type and features visual position indicators for Ready, Buffering, Inhibit, and PC-mode. Protection functions include output overvoltage protection with a typical 32Vdc and a maximum of 35Vdc, and overload/short-circuit protection with a minimum of 17.9A and a maximum of 21A at load impedance. Series or parallel operation is not supported. The output voltage is a fixed 24Vdc, with a turn-ON voltage of 23Vdc, and it boasts an efficiency of 0.978 at a 24Vdc input. The rated power is 360W at 24Vdc, with hold times of 16.5s at 10A and 9s at 15A. Power dissipation/losses are 2.9W at 0A output current and 4.6W at 10A output current, with a ripple of 30mVpp across 20Hz to 20MHz at 50Ω. Its electrical durability ranges from 324000 hours at 25°C and 10A output to 34000 hours at 55°C and 15A output. The capacitance of the output stage is 1500µF. | Puls | $1,000.00 | Quick Quote | |
| CS10.241 PULS CS10.241 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for a single-phase network. It operates within an ambient air temperature range of -25 to +70°C and supports a supply voltage range of 85Vac-132Vac / 184Vac-264Vac with auto-selection, featuring an 80Vac turn-ON voltage and a 75Vac shutdown voltage. The unit provides an adjustable output voltage of 24Vdc-28Vdc, with a rated current of 12A at an ambient temperature of less than 45°C and 10A at less than 60°C for 24Vdc, and slightly different ratings for 28Vdc. It has a rated power of 288W at less than 45°C ambient temperature and 240W at less than 60°C. The CS10.241 exhibits a current consumption of 2.23A at 230Vac input for full 24Vdc output, with varying consumption rates at 120Vac and 100Vac inputs, and a peak inrush current of 10A across all input voltages. It features an efficiency of up to 0.916 depending on the input voltage, with dimensions of W60mm x H124mm x D117mm. The unit includes a time delay of 850ms for start-up and offers protection functions such as output overvoltage protection and overload/short-circuit current protection. It supports series/parallel operation for redundancy and is resistant to back-feeding loads up to 35V. The power dissipation/losses are specified for different input conditions, and the electrical durability varies with operating conditions, reaching up to 334000 hours at 25°C with a 5A output at 230Vac input. The output stage capacitance is 7000µF, and the ripple is maintained at 50mVpp. Connection is facilitated through screw-clamp connections, and the design includes a 20% power reserve with a DC-OK relay contact output. | Puls | $365.00 | Quick Quote | |
| PISA11.401 PULS PISA11.401 is a protection unit designed as a 4-channel protection module with 1 input and 4 outputs, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and adheres to NEC Class 2 design specifications. The rated current is 20A, distributed as 6A + 6A + 12A + 12A with a derating of 0.025A/+60°C to +70°C for each channel. It features screw-clamp connections for secure installation. As part of the PISA11-series, this unit has dimensions of W45mm x H75mm x D91mm and requires a supply voltage of 18Vdc to 30Vdc, with 24Vdc being typical and 21.4Vdc needed to turn on the outputs. The output voltage is adjustable between 24Vdc and 28Vdc. Protection functions include short-circuit protection with an 8ms shutdown time and current limitation with a 20.5A to 30A adjustable threshold. Power dissipation at full output load with a 24V input is 4.2W. The processing time for turn-on delay of output is 270ms, and the voltage drop across channels 1+2 and 3+4 is 178mV and 182mV, respectively. Electrical durability is rated at 171,000 hours at 40°C and 485,000 hours at 25°C for outputs of 2x3A and 2x5A. | Puls | Quick Quote | ||
| PISA11.410 PULS PISA11.410 is a protection unit designed as a 4-channel protection module with 1 input and 4 outputs, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and is designed according to NEC Class 2 standards. The rated current is 14.8A at 24Vdc, with screw-clamp connections for secure installation. As part of the PISA11-series, it measures 45mm in width, 75mm in height, and 91mm in depth. The supply voltage requirement ranges from 18Vdc to 30Vdc, with a specific input voltage of 21.4Vdc needed to activate the outputs. The output voltage is adjustable between 24Vdc and 28Vdc. Protection functions include short-circuit protection with a 10ms shutdown time and current limitation with an adjustable threshold between 16.6A and 23.6A. Power dissipation at full output load with a 24V input is 1.6W. The processing time for turn-on delay of output is 270ms, and the voltage drop is 92mV at 24V and 81mV at 28V. Electrical durability is rated at 220,000 hours at 40°C with 4x1.9A output and 622,000 hours at 25°C with 4x1.9A output. | Puls | Quick Quote | ||
| QS40.484 PULS QS40.484 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. Connection is facilitated through screw-clamp connections, and it supports a supply voltage range of 180Vac to 264Vac, accommodating various nominal voltages within this range at a frequency of 47-63Hz. The QS40.484, part of the Q-series, measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase network operation and delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation to increase output power. Efficiency is rated at 0.95 with a 230Vac input, and the unit exhibits a peak current consumption of 18A. Start-up and rise times are specified as 750ms and 18-35ms respectively, with a hold time of 30ms at 230Vac input. Power dissipation losses are detailed for both 230Vac and 120Vac inputs, and the electrical durability spans from 65,000 to 345,000 hours under various conditions. Ripple is maintained at 150mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 3700µF. | Puls | Quick Quote | ||
| QT20.361 PULS QT20.361 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 13.3A at 36Vdc and 11.4A at 42Vdc, with a power derating from 12W at +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac across various nominal voltages (380Vac to 525Vac) at 47-63Hz, with a 3-phase input. The QT20.361, part of the Q-series, measures 65mm in width, 124mm in height, and 127mm in depth, housed in aluminium. It is designed for a 3-phase network, with a rated power of 480W at 36Vdc and 42Vdc, and can momentarily support up to 720W for 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with protection functions including output overvoltage protection and active input inrush current limiting. It allows for series or parallel operation for increased output power and is resistant to back-feeding loads up to 48V. The unit boasts an efficiency of up to 0.948, with a peak current consumption of 10A at inrush. It features a start-up delay of 290-350ms, a rise time of 30-40ms depending on load capacitance, and a hold time of 22ms. Power dissipation is 27.4W at full output load with a 3x480Vac input and 26.3W with a 3x400Vac input. Its electrical durability ranges from 48,000 to 250,000 hours, depending on operating conditions, with a ripple of 100mVpp and an output stage capacitance of 500µF. | Puls | Quick Quote | ||
| SLD2.100 PULS SLD2.100 is a power supply unit featuring galvanic isolation and a DC-OK relay contact output. It serves as both an AC/DC power supply unit (PSU) and a DC/DC converter, equipped with screw-clamp connections for secure installation. The dimensions of this unit are W49mm x H124mm x D102mm, designed for DIN rail mounting, making it suitable for compact spaces. It operates with a supply voltage range of 18Vdc-36Vdc (24Vdc nominal) and delivers a rated current of 8A at 4.5Vdc with a power derating from +60°C to +70°C. The ambient air temperature for operation spans from 0 to +70 °C. The SLD2.100 consumes 2.9A at full 18Vdc output and 1.5A at full 36Vdc output, supporting both series and parallel operation. The output voltage is adjustable between 4.5-5.5Vdc, with an efficiency of 0.82 at 24Vdc input. This unit offers a rated power of 40W, a hold time of 10ms at 24Vdc input, and experiences power dissipation/losses of 8.5W at 24Vdc input with a full output load. Additionally, it features a 300ms start-up delay and maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
