804-104 WAGO Industrial Automation Components

WAGO 804-104 is an automation part designed for printed circuit connections, featuring a short circuit breaking rating as per IEC/EN 60664-1 standards. It operates at nominal voltages of 250V (III/3), 320V (III/2), and 630V (II/2) with a rated impulse voltage of 4kV across these categories and a rated current of 24A. UL and CSA approvals are included, with rated voltages of 300V and rated currents of 10A for both Use Groups B and D. This part accommodates four connection points and offers a single connection type across one level, utilizing Push-in CAGE CLAMP technology with push-button actuation. It accepts solid and fine-stranded conductors ranging from 0.25 to 2.5mm2 (20 to 12 AWG), including fine-stranded conductors with both insulated and uninsulated ferrules. The strip length for connections is specified between 10 and 11mm, with a conductor connection direction to PCB at 0° and a pole number of 4. Physically, it has a pin spacing of 5mm, dimensions of 21.5mm in width, 18.1mm in height, 15mm in depth, and a solder pin length of 3.6mm. The terminal block is made from Polyamide (PA66) in gray, meeting the UL94 V0 flammability class, with chrome-nickel spring steel (CrNi) for the clamping spring and electrolytic copper (ECu) with tin plating for contacts. It operates within a temperature range of -60 to +105°C, weighs 4.2g, and is RoHS compliant without exemptions. The product is packaged in boxes of 220 pieces, with a country of origin of CH and a GTIN of 4044918515009.
