750-455 WAGO Industrial Automation Components

Wago 750-455 is an I/O unit designed as a standard analog input slice module. It operates with a supply voltage of 5Vdc provided by the system and offers an adjustable supply voltage of 18-32.5Vdc to field sensing devices. This unit features push-in spring cage-clamp connections and is designed with 4 x common ground potential. It is specified for an ambient air temperature range for operation from -40°C to +55°C and for storage from -40°C to +85°C. The 750-455 supports an IP20 communication protocol and has a rated insulation voltage (Ui) of 12 mm. Its dimensions are H100mm x W12mm x D69.8mm, and it is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. The module accommodates 4 x analog inputs (4-20mA) with a single-ended connection and features a 12-bits / 10ms conversion rate. It has a vibration resistance according to EN 60068-2-6 of 4g and a shock resistance according to EN 60068-2-27 of 15g. The climatic resistance is rated at 65mA (5Vdc system supply) with a control circuit rated current accuracy of +-0.1% (measuring error) and +-0.01% (temperature error). The response time is 10 ms, and it is designed to withstand 95% relative humidity (RH, non-condensing).
