256-601 WAGO Industrial Automation Components

WAGO 256-601 is an automation part with a short circuit breaking rating and electrical data compliant with IEC/EN 60664-1 standards. It features a nominal voltage of 500V (III/3), 630V (III/2), and 1000V (II/2), with a rated impulse voltage of 6kV across these categories. The rated current is 24A. For UL ratings, it has a rated voltage of 300V and rated currents of 15A for Use Group B and 10A for Use Group D, similarly rated under CSA. It offers a single connection point with one potential and utilizes CAGE CLAMP technology with push-button actuation. The part accommodates solid and fine-stranded conductors ranging from 0.08 to 2.5mm2 (28 to 12 AWG), including options for ferruled conductors. The strip length for connections is 5 to 6mm, with a conductor connection direction to PCB at 45 degrees. Physically, it has a pin spacing of 10/10.16mm, dimensions of 12.8mm in width, 22.2mm in height, 17.6mm in depth, and a solder pin length of 4mm. The insulation material is Polyamide (PA66), with a flammability class of V0 and clamping spring material of Chrome-Nickel spring steel. It operates within a temperature range of -60 to +105°C. The product is RoHS compliant, packaged in boxes of 300 pieces, and has a GTIN of 4044918809061.
