LUS211-40-51-LI2UPN8-H1141 Turck Level Sensors
Part#:LUS211-40-51-LI2UPN8-H1141
Manufacturer:Turck
Alt. Part#:100003167
Product Lifecycle:Active
Get a quick Quote!
LUS211-40-51-LI2UPN8-H1141 Ultrasonic Sensor, Level Control
About the manufacturer: Turck is one of the manufacturers that offers Level Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the LUS211-40-51-LI2UPN8-H1141 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 381 g
- Country Of Origin DEU
- HTS Code 8536507000
- Protection class IP6K6K / 6K7 / 6K9K
- Ambient temperature -25…+70 °C
- Housing material Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV PA
- Electrical connection Connector, M12 × 1
- Communication protocol IO-Link
- Current output 4…20 mA
- Voltage output 0…10 V
- Output function NO/NC, PNP/NPN, analog output
- Operating voltage 18…33 VDC
- Max. range 400 mm
- Medium liquids, Bulk goods
- Process connection G 3/4”
- Measuring principle Ultrasonic
- Detection type contactless
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
LUS211-40-51-LI2UPN8-H1141 Description
Turck LUS211-40-51-LI2UPN8-H1141 is a sensor designed for liquid level measurement within the LUS211 series. This instrumentation liquid level ultrasonic sensor features a cylindrical shape and is constructed with a 1.4404 (316L) stainless steel housing. It is pre-equipped with a 4-pin M12 Eurofast QD male connector and a G3/4" threaded male process connection for installation. The sensor operates on a supply voltage range of 17-33Vdc, with a nominal voltage of 24Vdc, and can function within an ambient air temperature range of -25°C to +70°C. It offers a degree of protection rated at IP67. The sensor provides 1 x analog output (4-20mA / 0-10Vdc; can also be used as a NPN/PNP digital output), with a current consumption of 150mA under no-load conditions. It has a sensing distance of 40cm / 400mm and operates at a frequency with a maximum switching frequency of 5Hz. The response time of the sensor is 60ms / 0.06 s.
Related documents LUS211-40-51-LI2UPN8-H1141 Specs
