XVBL36 Schneider Electric Industrial Automation Components

XVBL36 on Powermatic Associates
Schneider Electric

Part#:XVBL36

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric XVBL36 is a modular tower light from the XVB sub-range, designed for illuminated beacon applications with steady light signaling in a single tier. This cylindrical-shaped unit offers a degree of protection rated at IP66 and IP65 when mounted on the fixing base XVBZ0. It operates with a control voltage of 250 Vac and 250 Vdc, and a supply voltage of 250 V for both AC and DC configurations. The XVBL36 features a diameter of 70 mm and emits a steady blue light, suitable for a variety of signaling applications.

Product Details

  • Terminals Description ISO N°1
    (COM-1)PW (GND)GROUND
  • Bulb Type
    Incandescent BA 15d Protected LED
  • Beacon Or Indicator Bank Unit Type
    Base unit direct or tube fixing Illuminated unit
  • Material
    Glass reinforced polyamide base unit Polycarbonate illuminated unit
  • CAD Overall Width
    2.76 in (70 mm)
  • Net Weight
    0.57 lb(US) (0.26 kg)
  • CAD Overall Depth
    2.76 in (70 mm)
  • CAD Overall Height
    5.47 in (139 mm)
  • [Uimp] Rated Impulse Withstand Voltage
    4 kV IEC 60947-1
  • Connections - Terminals
    Screw clamp terminals, <= 1 x 1.5 mm² with cable end
  • Nominal Voltage Limit
    0.85...1.1 Un IEC 60947-5-1
  • [Ui] Rated Insulation Voltage
    250 V IEC 60947-1
  • Maximum Power Dissipation In W
    7 W
  • [Us] Rated Supply Voltage
    <= 250 V
  • Light Source
    Bulb not included, blue
  • Mounting Diameter
    2.76 in (70 mm)
  • Component Name
    XVBL
  • Signalling Type
    Steady
  • Range Of Product
    Harmony XVB Universal
  • Product Or Component Type
    Complete beacon

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of XVBL36 on Powermatic Associates is $114.00. Order now.

XVBL36 Related Documents

Catalog-1631038599018.pdfInstruction Sheet-1631038599016.pdfProduct Datasheet-1631038599022.pdf
