Part#:QO2701021

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QO2701021 is a Miniature Circuit Breaker (MCB) featuring a shunt trip coil. It is designed for plug-in mounting and has a rated current of 70A with a plug-in connection type. This MCB operates at a rated voltage of 48Vdc and 120V/240V AC, accommodating a cross-section of 8-2AWG for 1 cable Al/Cu. It is a 2 Pole device with control voltage ranging from 120Vac to 208Vac. The short circuit breaking rating is specified at 10kA for 240Vac and 5kA for 48Vdc, and it utilizes box lugs as its type of terminals.

Product Details

  • Voltage Rating
    120/240 V AC 120 V AC 48 V DC
  • Interrupt Rating
    10 kA 120/240 V AC 50/60 Hz 10 kA 120 V AC 50/60 Hz 5 kA 48 V DC
  • Depth
    2.91 in (73.91 mm)
  • Electrical Connection
    Box lugs
  • Wire Size
    AWG 8...AWG 2 copper or aluminium
  • Options
    Shunt trip 120/208/240 V AC
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.02…0.04 in² (10…25 mm²) (AWG 8...AWG 2)
  • Width
    2.25 in (57.15 mm)
  • Height
    3.12 in (79.25 mm)
  • Number Of Panel Spaces
    3
  • Ratings
    HACR rated
  • Circuit Breaker Type
    Standard
  • Number Of Poles
    2P
  • Current Rating
    70 A
  • Mounting Type
    Plug-in
  • Product
    Miniature circuit-breaker
  • Range
    QO

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QO2701021 on Powermatic Associates is $484.50. Order now.
