Part#:EGB34100LC

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

E-Frame Brkr 100A, 3P, 480Y/277V, 35/65kA, Bolt-on Mnt, Copper Lugs

Product Details

  • Breaking Capacity
    35 kA 277 V AC 65 kA 240 V AC 35 kA 480Y/277 V AC 65 kA 120 V AC 65 kA 120/240 V AC
  • Protection Type
    Overload Short-circuit
  • Depth
    4.05 in (102.87 mm)
  • Net Weight
    4 lb(US) (1.81 kg)
  • Width
    2.94 in (74.68 mm)
  • Height
    5.66 in (143.76 mm)
  • Breaking Capacity Code
    G
  • Trip Unit Technology
    Thermal-magnetic
  • Number Of Spaces Required
    3
  • Product Destination
    NF panelboard
  • Number Of Poles
    3
  • Number Of Spaces
    3
  • Electrical Connection
    Lugs copper
  • Holding Current
    1000 A
  • Local Signalling
    Trip indicator
  • Mounting Mode
    Bolt-on
  • Circuit Breaker Application
    HACR rated
  • Line Rated Current
    100 A
  • Device Short Name
    EGB
  • AWG Gauge
    AWG 14...AWG 1/0 copper cable
  • Trip Unit Rating
    2300 A
  • Maximum Operating Voltage
    480Y/277 V AC
  • Module Type
    E-Frame
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Product Or Component Type
    Miniature circuit-breaker

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EGB34100LC on Powermatic Associates is $1,550.00. Order now.

EGB34100LC Related Documents

Product Datasheet-1631035342407.pdfInstruction Sheet-1631035342412.pdfCatalog-1631035342419.pdf
