PN14-8R-M Panduit Electronic Components

Product Details

• Part Features
  • Ring tongue design assures a secure connection in high vibration applications • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications • Internal barrel serrations assure goo
• Product Type
  Loose Piece Ring Terminal
• Tongue Width (mm)
  7.9
• Tongue Width (In.)
  0.31
• Tongue Thickness (mm)
  0.8
• Tongue Thickness (In.)
  0.03
• Sub Brand
  Pan-Term®
• Maximum Wire Insulation Diameter (mm)
  4.1
• For Use With
  CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
• Packaging Type
  Box
• Overall Width (mm)
  7.9
• Overall Length (In.)
  0.85
• Overall Width (In.)
  0.31
• Overall Length (mm)
  21.6
• Maximum Wire Insulation Diameter (In.)
  0.16
• Maximum Operating Temperature (°C)
  105
• Maximum Operating Temperature (°F)
  221
• Flammability Rating
  UL94-HB
• Barrel Type
  Grip Sleeve
• Color Code
  Blue
Maximum Voltage (kV)
0.6
Finish/Coating
Tin-Plated
Maximum Voltage (V)
600
Base Material
Copper
Minimum Metric Conductor Size (mm²)
1
Wire Strip Length (mm)
5.6
Maximum Metric Conductor Size (mm²)
2.5
Wire Strip Length (In.)
7/32
Standards Met
UL 486A/B, and CSA 22.2 No.65
Minimum Copper Conductor Size (AWG STR)
#18
Minimum Copper Conductor Size (AWG SOL)
#18
Minimum Wire Size (AWG)
#18
Maximum Wire Size (AWG)
#14
Maximum Copper Conductor Size (AWG SOL)
#14
Maximum Copper Conductor Size (AWG STR)
#14
Insulation Material
Nylon
Stud Size
#8

Related documents PN14-8R-M Specs
