CX-04TF Mencom Electronic Components

CX-04TF on Powermatic Associates
Mencom

Part#:CX-04TF

Manufacturer:Mencom

Category:Electronic Components

Product Lifecycle:Active

In-stock parts: 14

Dec 21, 2024

MIXO Frame for housings, Size 77.27, For 4 Module

About the manufacturer: Mencom is one of the manufacturers that offers Electronic Components that you can order at Powermatic Associates site. Since 1987, Mencom Corporation has been your go-to source for affordable industrial electrical connector solutions. Count on our experienced team to deliver top-quality products with unwavering dedication.

Check out the CX-04TF Mencom price in the box on the right side or send a quick quote.

Product Details

  • Weight (lbs.)
    0.133000
  • Temperature Range in Degrees Celsius
    -40 C to +125 C
  • Product Type
    Accessory
  • Cover
    No
  • Component Type
    Accessory
  • Housing/Insert Type
    MIXO
  • Gender
    Male
  • Insert Dimension
    77.27
  • Gasket/O-Ring
    No
  • Number of Entries
    0
  • Enclosure Dimension
    77.27
  • ILME Series
    MIXO

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents CX-04TF Specs

CX-04TF CX-04TF.PDF-1631088927320.pdf
CX-04TF CX-04TF.DWG-1631088927322.dwg
CX-04TF 317.pdf-1631088927329.pdf
CX-04TF CX-04TF.ZIP-1631088927333.zip
CX-04TF CX-04TF.DXF-1631088927325.dxf

This item can ship within 24h!

Manufacturer warranty

$24.68

Stock:

14

Select Qty:

$24.68

$24.68 each
