FLEXY10200_00MA HMS Networks Industrial Automation Components

Product Details

• Vibration and Shock
  Vibration & shocks tested according to: IEC 60068-2-27 Bumps, IEC 60068-2-64 Vibration (broad-band random), IEC 60068-2-6 Vibration (sinusoidal)
• Waste Certification (WEEE)
  Yes
• Model Code
  00301
• HS Code
  8517699000
• Export Control Classification Number (ECCN) (ERP)
  5A992.c
• Dual Usage (ERP)
  No
• Country of Origin
  Belgium
• Connectors / Input / Output
  1x RJ45 Ethernet port: 10/100Mb, 1x Male SUBD9 Serial port: configurable by software in RS232/485/422, 1.5kV functional isolation from power supply, 2x Digital input: 0 to 12/24VDC; 1.5kV isolation, 1x Digital output: open drain (MOSFET) 200mA; 1.5 kV iso
• Contains Battery
  Yes
• Environment
  Temperature - Operating & Storage tested according to: IEC 60068-2-1 Cold test, IEC 60068-2-2 Dry heat test, IEC 60068-2-14 Change of temperature, IEC 60068-2-30 Cyclic damp heat test
• WEEE Category
  IT and telecommunications equipment
• UKCA
  Yes
• FCC
  Yes
• IC
  Yes
• RCM
  No
• CE
  Yes
• KC
  No
• VPN Security
  VPN sessions are end-to-end encrypted using SSL/TLS protocol. Communications between the remote user and the Ewon are fully encrypted using the SSL/TLS protocol, thereby ensuring data authenticity, integrity & confidentiality. Indeed, all users and Ewon u
• Data Acquisition Protocols
  OPC UA, Modbus RTU, Modbus-TCP, Unitelway, DF1, PPI, MPI, PROFIBUS, FINS Hostlink, FINS TCP, EtherNet/IP, ISO TCP, Mitsubishi FX, Mitsubishi MELSEC, Hitachi EH, ASCII, BACnet/IP
• Data Publishing Protocols
  OPC UA, Modbus, MQTT, SNMP, HTTPS
UL
Yes
Router Features
No VPN to LAN routing.
Data Logging
Define up to 2500 internal tags. Internal database for data logging (real-time logging and historical logging up to 1,000,000 timestamps). Historical data can be exported to DataMailbox or transferred by FTP or email.
Warranty (years)
3
VPN
OpenVPN either in SSL UDP or TCP.
Configuration
Web-Based configuration: Embedded web interface with setup wizards for configuration and maintenance (no extra software needed). Authentication with login/password and user management capability. Possibility of uploading custom web GUI.
Packaging Material
Cardboard
Relative Humidity
10 to 95% relative humidity (non-condensing).
Housing Materials
Plastic
Storage Temperature °C Max
+70 °C
Storage Temperature °C Min
-30 °C
Operating Temperature °C Max
+60 °C
Net Weight (ERP) (g)
305 g
Content of Delivery
This product consists of the following components: an industrial gateway in a plastic housing, a power connector, 4 pcs of Flexy blank extension front plates, a start-up guide document in paper version, legal references in paper version and a branded card
Power Connector
9-pole
Net Depth (ERP) (mm)
88 mm
Operating Temperature °C Min
-25 °C
Input Voltage (V)
12 - 24VDC +/-20%, LPS.Consumption: depending on the extension card installed (see Installation guide on our website).
Not Included (in delivery)
Any variant of extension boards and their accessories (antenna, cable)
Mounting
DIN rail mount (bracket included)
Net Height (ERP) (mm)
79 mm
Net Width (ERP) (mm)
133 mm
