AB7321-B HMS Networks Industrial Automation Components

Product Details

• CC-Link Configuration File
  CSP available
• CANopen Output Data Size
  512 bytes
• CAN Mode
  Generic CAN
• CANopen Input Data Size
  512 bytes
• CANopen Mode
  Generic CAN
• CC-Link Input Data Size
  896 bits/128 words (368 bytes)
• CANopen Supported Functionality
  CAN standards 2.0A/2.0B; Byte swap; 128 CAN transactions; Produce / Consume; Cyclic, On data change, Single Shot, Trigger update modes;
• Export Control Classification Number (ECCN) (ERP)
  5A991.b.4b
• CC-Link Supported Functionality
  CC-Link slave Version 1 and 2; Transparent CC-Link; PLC Profile compliant; 4 occupied stations; 8 extension cycles
• HS Code
  8517620000
• CANopen Baud Rate
  20 kBit/s to 1 Mbit/s
• CC-Link Mode
  Slave
• CC-Link Output Data Size
  896 bits/128 words (368 bytes)
• Dual Usage (ERP)
  No
• CAN Baud Rate
  20 kBit/s to 1 Mbit/s
• DIP & Rotary Switches
  3x Rotary CAN Address + Baudrate
• Country of Origin
  Sweden
• Contains Battery
  No
• Connectors / Input / Output
  male 9-DSUB, 1x 5-pin, 5.08 Phoenix plug connector
• WEEE Category
  IT and telecommunications equipment
Recycle / Disposal
TRUE
RoHS Compliant
Yes
Environment
EN 61000-6-4, EN 55016-2-3 Class A, EN 55022 Class A, EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
Protection Class IP
IP20, IP54
Waste Certification (WEEE)
Yes
EMC
Yes
FCC
No
ATEX Code
II 3 G Ex nA ic IIC T4 Gc, EN 60079-0; EN60079-15; EN60079-11
Housing Materials
Plastic
Packaging Material
Cardboard
CE
Yes
UL File Number
E214107: Ord.Loc UL508, CSA C22.2 NO. 142; E203225: Haz.Loc CL I DIV2 GP A,B,C,D T4, ANSI/ISA 12.12.01, CAN/CSA C22.2 No. 213, CAN/CSA C22.2 No. 142
UL
Yes
Operating Temperature °C Max
55 °C
Storage Temperature °C Min
-40 °C
Reverse Polarity Protection
Yes
Net Width (ERP) (mm)
27 mm
Net Depth (ERP) (mm)
75 mm
Storage Temperature °C Max
85 °C
Operating Temperature °C Min
-25 °C
Isolation
TRUE
Short Circuit Protection
Yes
Current Consumption Max value at Vcc nom (mA)
250mA @ 24V DC
Net Weight (ERP) (g)
300 g
Net Height (ERP) (mm)
120 mm
Input Voltage (V)
24V DC (-10% to +10%)
Mounting
DIN-rail (EN 50022 standard)
Power Connector
2-pin, 5.08 Phoenix plug connector
Current Consumption Type Value at Vcc Nom (mA)
100mA @ 24V DC
Manufacturer description
Anybus Communicator Serial Gateways - CC-Link Slave - CAN Gateways
Primary brand
eWON by HMS Networks
Customs Tariff Number
8517620090
