8099218 Festo Cable Assemblies

8099218 on Powermatic Associates
Festo

Part#:8099218

Alt. Part#:NEBC-M8G4-ES-1.5-N-SB-S1G9-RS2-S7

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

connecting cable NEBC-M8G4-ES-1.5-N-SB-S1G9-RS2-S7 Protocol: RS232, Cable identification: with accessories, Assembly position: Any, Electrical connection 1, function: Field device side, Electrical connection 1, design: Round

Product Details

  • Cable diameter
    4.6 mm
  • Note on degree of protection
    IP20 for Sub-D socket In mounted state
  • Protocol
    RS232
  • Electrical connection 1, design
    Round
  • Electrical connection 1, cable outlet
    Straight
  • Electrical connection 2, function
    Control side
  • Electrical connection 2, cable outlet
    Straight
  • Electrical connection 2, type of mounting
    2x screw, 4-40 UNC
  • Cable length
    1.5 m
  • Cable designation
    With accessories
  • Electrical connection 1, connection type
    Plug
  • Electrical connection 1, occupied pins/wires
    3
  • Electrical connection 2, connection type
    Socket
  • Electrical connection 2, design
    Rectangular
  • Electrical connection 2, connection pattern
    00995638
  • Current rating at 40°C
    4 A
  • Bending radius, fixed cable installation
    ≥ 24 mm
  • Cable design
    3 x 0.34 mm²
  • Material of cable sheath
    TPE-U(PUR)
  • Type code
    NEBC
  • Electrical connection 1, function
    Field device end
  • Electrical connection 1, connection technology
    M8x1 A-coded as per EN 61076-2-104
  • Electrical connection for input 1, connection pattern
    00995708
  • Electrical connection 2, occupied pins/wires
    8
  • Nominal operating voltage DC
    24 V
  • Connector cable test conditions
    Test conditions on request
  • Ambient temperature
    0 °C ... 50 °C
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Color cable sheath
    Black
  • Shield
    yes
  • Electrical connection 1, number of pins/wires
    4
  • Electrical connection 2, connection technology
    Sub-D
  • DC operating voltage range
    0 V ... 24 V
  • Cable characteristic
    Suitable for energy chains
  • Bending radius, flexible cable installation
    ≥ 47 mm
  • Degree of protection
    IP67
  • Electrical connection 1, type of mounting
    Screw-type lock
  • Electrical connection 2, number of pins/wires
    9
  • Surge resistance
    1.5 kV
  • Cable diameter tolerance
    ± 0.1 mm
  • Nominal conductor cross section
    0.34 mm²
  • Contamination level
    2
  • Mounting position
    Any
  • Ambient temperature with flexible cable installation
    0 °C ... 50 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
