550326 Festo Cable Assemblies

Name: 550326
Brand: Festo
Price: 20.47 USD
Availability: InStock

Part#:550326

Manufacturer:Festo

Alt. Part#:NEBU-M12G5-K-2.5-LE4

Product Lifecycle:Active

In-stock parts: 1

Nov 16, 2024

connecting cable NEBU-M12G5-K-2.5-LE4 For SOPA air gap sensor. Conforms to standard: (* Core colours and connection numbers to EN 60947-5-2, * EN 61076-2-101), Cable identification: with 2x label holders, Product weight: 77 g, Electrical connection 1, fun

About the manufacturer: Festo is one of the manufacturers that offers Cable Assemblies that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 550326 Festo price in the box on the right side or send a quick quote.

Product Details

Seals material
NBR
Conforms to standard
Wire colors and connection numbers as per EN 60947-5-2 EN 61076-2-101
Product weight
77 g
Electrical connection 1, cable outlet
Straight
Electrical connection 1, number of pins/wires
5
Electrical connection 2, connection type
Cable
Operating voltage range AC
0 V ... 250 V
Cable length
2.5 m
Bending radius, flexible cable installation
46 mm
Degree of protection
IP65 IP69K
Nominal conductor cross section
0.25 mm²
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Electrical connection 1, connection type
Socket
Electrical connection 2, function
Control side
Electrical connection 2, number of pins/wires
4
Current rating at 40°C
4 A
Bending radius, fixed cable installation
14 mm
Note on degree of protection
In mounted state
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
Material of cable sheath
TPE-U(PUR)

Material of screw-type lock

Brass, nickel-plated

Material of pin contacts

Copper alloy, gold-plated

Explosion prevention and protection

Observe the information on the certificate Zone 22 (ATEX)

Electrical connection 1, function

Field device end

Electrical connection 1, connection technology

M12x1 A-coded as per EN 61076-2-101

Electrical connection for input 1, connection pattern

00991861

Surge resistance

2.5 kV

Cable design

4 x 0.25 mm²

CE marking (see declaration of conformity)

As per EU low voltage directive As per EU RoHS directive

Color cable sheath

Gray

Type code

NEBU

Electrical connection 1, type of mounting

Screw-type lock

Electrical connection 2, occupied pins/wires

Connector cable test conditions

Flexural strength: as per Festo standard Cable chain: 5 million cycles, bending radius 75 mm

Cable diameter tolerance

± 0.1 mm

Ambient temperature

-25 °C ... 70 °C

Note on materials

Free of copper and PTFE Free of phosphoric acid ester

Housing material

TPE-U(PUR)

Cable designation

With 2x label holders

Electrical connection 1, design

Round

Electrical connection 1, occupied pins/wires

Electrical connection 2, connection technology

Open end

DC operating voltage range

0 V ... 250 V

Cable characteristic

Standard

Cable diameter

4.5 mm

Special features

Oil-resistant

Contamination level

Housing colour

Black

Insulating sheath material

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
