578335 Festo Pneumatic Fittings

578335 on Powermatic Associates
Festo

Part#:578335

Alt. Part#:NPQH-D-M5-Q6-P10

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

9 in stock

Apr 25, 2025

Product description

push-in fitting NPQH-D-M5-Q6-P10 Size: Standard, Nominal size: 2,5 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10

Product Details

  • Nominal width
    2.5 mm
  • Pack size
    10
  • Certificate issuing authority
    NSF C0523185
  • Type of seal on screwed trunnion
    Sealing ring
  • Operating pressure for entire temperature range
    -0.95 bar ... 20 bar
  • Design
    Push-pull principle
  • Size
    Standard
  • Mounting position
    Any
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Ambient temperature
    0 °C ... 150 °C
  • Product weight
    11.2 g
  • Releasing ring material
    Brass, nickel-plated
  • Corrosion resistance class (CRC)
    3 - High corrosion stress
  • Pneumatic connection 1
    External thread M5
  • Type code
    NPQH
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Max. tightening torque
    1.5 Nm
  • Material of threaded seal
    FPM
  • For use in the food industry
    See declaration of conformity NSF/ANSI 169
  • Note on materials
    RoHS-compliant
  • Material of tube retaining claw
    High-alloy stainless steel
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 6 mm
  • Housing material
    Brass, nickel-plated
  • Material of tubing seal
    FPM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
