5736 Festo Pneumatic Components

5736 on Powermatic Associates
Festo

Part#:5736

Alt. Part#:CJ-5/2-1/4

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

pneumatic valve CJ-5/2-1/4 Without sub-base Valve function: 5/2 bistable, Type of actuation: pneumatic, Standard nominal flow rate: 1400 l/min, Operating pressure: 1 - 16 bar, Nominal size: 6,5 mm

Product Details

  • Standard nominal flow rate
    1400 l/min
  • Type code
    CJ
  • Pilot pressure
    2 bar ... 10 bar
  • Type of mounting
    On sub-base
  • Pneumatic connection 3
    G1/4
  • Pneumatic connection 4
    G1/4
  • Diaphragm material
    PUR
  • Pneumatic working port
    G1/4
  • Symbol
    00991002
  • Pilot air port 12
    G1/8
  • Seals material
    NBR
  • Mounting position
    Any
  • On switching time
    28 ms
  • Max. switching frequency
    40 Hz
  • Pneumatic connection 1
    G1/4
  • Note on materials
    Contains paint-wetting impairment substances
  • Actuation type
    Pneumatic
  • Operating pressure
    1 bar ... 16 bar
  • Manual override
    Non-detenting
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Temperature of medium
    -10 °C ... 60 °C
  • Pilot air port 14
    G1/8
  • Pneumatic connection 5
    G1/4
  • Housing material
    Wrought aluminum alloy
  • Valve function
    5/2, bistable
  • Nominal width
    6.5 mm
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Pneumatic connection 2
    G¼

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
