571900 Festo Cable Assemblies

571900 on Powermatic Associates
Festo

Part#:571900

Alt. Part#:NEBM-M12G4-RS-2.23-N-M12G4H

Manufacturer:Festo

Category:Cable Assemblies

Product Lifecycle:Active

Product description

motor cable NEBM-M12G4-RS-2.23-N-M12G4H Conforms to standard: (* DIN 47100, * EN 61984), Cable identification: Without inscription label holder, Electrical connection 1, function: Field device side, Electrical connection 1, design: Round, Electrical conne

Product Details

  • Conforms to standard
    DIN 47100 EN 61984
  • Electrical connection 1, design
    Round
  • Cable designation
    Without label holder
  • Electrical connection 1, connection type
    Socket
  • Electrical connection 2, connection type
    Plug
  • DC operating voltage range
    0 V ... 250 V
  • Electrical connection 1, cable outlet
    Straight
  • Electrical connection 1, type of mounting
    Screw-type lock with AF 14
  • Electrical connection 2, design
    Round
  • Electrical connection 2, connection pattern
    00995386
  • Cable characteristic
    Suitable for robot applications
  • Type code
    NEBM
  • Electrical connection 1, function
    Field device end
  • Electrical connection for input 1, connection pattern
    00995385
  • Electrical connection 2, connection technology
    M12x1 A-coded as per EN 61076-2-101
  • Cable length
    2.23 m
  • Degree of protection
    IP67
  • Note on materials
    RoHS-compliant
  • Color cable sheath
    Black
  • Seals material
    NBR
  • Electrical connection 1, number of pins/wires
    4
  • Electrical connection 1, occupied pins/wires
    4
  • Electrical connection 2, cable outlet
    Straight
  • Electrical connection 2, occupied pins/wires
    4
  • Cable diameter
    5.9 mm
  • Note on degree of protection
    In mounted state
  • Ambient temperature with flexible cable installation
    0 °C ... 40 °C
  • Contamination level
    3
  • Electrical connection 1, connection technology
    M12x1 A-coded as per EN 61076-2-101
  • Electrical connection 2, function
    Control side
  • Electrical connection 2, number of pins/wires
    4
  • Electrical connection 2, type of mounting
    Screw-type lock with hexagon, AF 18
  • Current rating at 40°C
    4 A
  • Bending radius, flexible cable installation
    ≥ 60 mm
  • Cable design
    4 x 0.34 mm² Shielded
  • Ambient temperature
    -25 °C ... 80 °C
  • Material of cable sheath
    TPE-U(PUR)
  • Housing material
    TPE-U(PUR)
  • Operating voltage range AC
    0 V ... 250 V
  • Nominal conductor cross section
    0.34 mm²
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Insulating sheath material
    TPE-E

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
