561009 Festo Pneumatic Valves Accessories
Part#:561009
Alt. Part#:VMPAL-AP-20-QS5/16"-1
Manufacturer:Festo
Category:Pneumatic Valves Accessories
Product Lifecycle:Active
Product description
sub-base VMPAL-AP-20-QS5/16"-1 Width: 21,2 mm, Length: 107,3 mm, Grid dimension: 21,2 mm, Valve size: 20 mm, Max. number of valve positions: 1
Product Details
- Pilot pressure MPa 0.3 MPa ... 0.8 MPa
- Width dimension 21.2 mm
- Max. no. of valve positions 1
- Max. no. of solenoid coils 1
- Product weight 76.78 g
- Width 21.2 mm
- Type code VMPAL
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Valve size 20 mm
- Flow direction Reversible
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Pneumatic connection 4 For pneumatic tubing outside diameter 5/16"
- Operating pressure -0.09 MPa ... 1 MPa
- Ambient temperature -5 °C ... 50 °C
- Note on materials RoHS-compliant
- Length 107.3 mm
- Valve manifold design Valve sizes can be mixed
- Pilot pressure 3 bar ... 8 bar
- Corrosion resistance class (CRC) 3 - High corrosion stress
- Pneumatic connection 2 for pneumatic tubing outside diameter 5/16"
- Material of sub-base PA-reinforced
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
561009 Related Documents
Similar products from: Festo Pneumatic Valves Accessories
Manufacturer warranty
561009 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 561009 with other Pneumatic Valves Accessories products
Pilot pressure MPa
Width dimension
Max. no. of valve positio...
Max. no. of solenoid coil...
Product weight
Width
Type code
Operating medium
Valve size
Flow direction
Selected product
561009
Festo
sub-base VMPAL-AP-20-QS5/16"-1 Width: 21,2 mm, Length: 107,3 mm, Grid dimension: 21,2 mm, Valve size...
Pilot pressure MPa0.3 MPa ... 0.8 MPa
Width dimension21.2 mm
Max. no. of valve positions1
Max. no. of solenoid coils1
Product weight76.78 g
Width21.2 mm
Type codeVMPAL
Operating mediumCompressed air as per ISO 85...
Valve size20 mm
Flow directionReversible
560947
Festo
end plate VMPAL-EPR-SP Width: 28,8 mm, Length: 107,3 mm, Integrated function: Pilot air selector for...
Pilot pressure MPa0.3 MPa ... 0.8 MPa
Width dimension-
Max. no. of valve positions-
Max. no. of solenoid coils-
Product weight-
Width28.8 mm
Type codeVMPAL
Operating medium-
Valve size-
Flow directionReversible
570783
Festo
end plate VMPAL-EPL-CPX Width: 40 mm, Length: 107,3 mm, Max. number of valve positions: 32, Valve te...
Pilot pressure MPa0.3 MPa ... 0.8 MPa
Width dimension-
Max. no. of valve positions32
Max. no. of solenoid coils32
Product weight-
Width40 mm
Type codeVMPAL
Operating medium-
Valve size-
Flow direction-
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...
About the Product Category
Accessories for pneumatic valves are elements that improve the performance of systems using compressed air. They allow for accurate control of actuators and consist of components like pressure relief valves and regulators. These accessories play a vital role in ensuring safety, managing flow rate, and guaranteeing the dependable functioning of pneumatic systems.
