570783 Festo Pneumatic Valves Accessories

570783 on Powermatic Associates
Festo

Part#:570783

Alt. Part#:VMPAL-EPL-CPX

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Apr 22, 2025

Product description

end plate VMPAL-EPL-CPX Width: 40 mm, Length: 107,3 mm, Max. number of valve positions: 32, Valve terminal structure: Valve sizes can be mixed, Max. number of solenoid coils: 32

Product Details

  • Electrical connection 1, connection technology
    Internally for CPX
  • Note on degree of protection
    In mounted state
  • Type code
    VMPAL
  • Corrosion resistance class (CRC)
    3 - High corrosion stress
  • Product weight
    130 g
  • Electrical connection 1, function
    Fieldbus
  • Valve manifold design
    Valve sizes can be mixed
  • Note on materials
    RoHS-compliant
  • Length
    107.3 mm
  • Pilot pressure
    3 bar ... 8 bar
  • Ambient temperature
    -5 °C ... 50 °C
  • Electrical connection 1, connection type
    Plug
  • Max. no. of valve positions
    32
  • Operating pressure
    -0.09 MPa ... 1 MPa
  • Nominal operating voltage DC
    24 V
  • Pilot pressure MPa
    0.3 MPa ... 0.8 MPa
  • Width
    40 mm
  • Max. no. of solenoid coils
    32
  • Degree of protection
    IP67
  • End plate material
    Die-cast aluminum PA-reinforced

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

570783 Related Documents

570783 DataSheet.pdf
