Part#:548086

Alt. Part#:DHTG-90-12-A

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Product description

rotary indexing table DHTG-90-12-A For position sensing. Size: 90, Parallelity poppet valve: <: 0,04 mm, Axial ecc poppet valve: <: 0,02 mm, Concentricity poppet valve: <: 0,02 mm, Repetition accuracy of the swivel angle: <: 0,03 deg

Product Details

  • Axial eccentricity of plate
    ≤ 0.02 mm
  • Type code
    DHTG
  • Size
    90
  • Parallelism of plate
    ≤ 0.04 mm
  • Symbol
    00992251
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Max. pull-out torque static
    150 Nm
  • Plate material
    Steel, galvanized
  • Housing material
    Wrought aluminum alloy
  • Repetition accuracy of swivel angle
    ≤ 0.03 deg
  • Position sensing
    For inductive proximity sensors
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    4500 g
  • Pneumatic connection
    Internal thread M5
  • Mounting position
    Any
  • Operating pressure
    4 bar ... 8 bar
  • Max. axial force static
    2000 N
  • Theoretical torque at 6 bar
    4.4 Nm
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Cover material
    Wrought aluminum alloy
  • Plate concentricity
    ≤ 0.02 mm
  • Cushioning
    Pneumatic shock absorber, hard characteristic curve, adjustable
  • Design
    Gear coupling Positively driven motion sequence
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Noise level
    ≤ 70 dB(A)
  • Max. tangential torque static
    150 Nm
  • Stops material
    Steel, galvanized
  • Mode of operation
    Double-acting
  • Spacing
    12
  • Ambient temperature
    5 °C ... 60 °C
  • Max. radial force static
    5000 N
  • Type of mounting
    Via through-hole and centering sleeve
  • Seals material
    NBR TPE-U(PU)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
