Part#:543178

Alt. Part#:CLR-32-10-L-P-A-B

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Product description

linear/swivel clamp CLR-32-10-L-P-A-B Clamping system with linear movement, standardised hole pattern to ISO 21287. Total stroke: 28 mm, Piston diameter: 32 mm, Piston rod thread: M8, Swivel angle: 90 deg +/- 2 deg, Clamping stroke: 10 mm

Product Details

  • Complete stroke
    28 mm
  • Clamping stroke
    10 mm
  • Position sensing
    For proximity sensor
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Product weight
    685 g
  • Cover material
    Wrought aluminum alloy Coated
  • Housing material
    Wrought aluminum alloy Smooth anodized
  • Piston diameter
    32 mm
  • Type code
    CLR
  • Symbol
    00991217
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Effective clamping force at 2 bar
    111 N
  • Type of mounting
    Optionally: With accessories
  • Flange screws material
    Steel Galvanized
  • Piston rod material
    High-alloy stainless steel
  • Swivel angle
    90 deg +/- 2 deg
  • Design
    Piston Cylinder barrel
  • Mode of operation
    Double-acting
  • Effective clamping force at 4 bar
    216 N
  • Theoretical clamping force at 6 bar
    362 N
  • Piston rod thread
    M8
  • Cushioning
    Elastic cushioning rings/pads at both ends
  • Mounting position
    Any
  • Operating pressure
    2 bar ... 10 bar
  • Ambient temperature
    -10 °C ... 80 °C
  • Effective clamping force at 6 bar
    313 N
  • Max. clamping finger screw tightening torque
    24 Nm
  • Seals material
    NBR TPE-U(PU)
  • Swivel direction
    Left
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Pneumatic connection
    G1/8
  • Material of cylinder barrel
    Wrought aluminum alloy Smooth anodized

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
