537701 Festo Pneumatic Components

Product Details

• Conforms to standard
  EN 60947-5-2
• Certification
  RCM compliance mark c UL us - Listed (OL)
• Measuring principle
  Optoelectronic
• Ambient temperature
  -25 °C ... 55 °C
• Switching element function
  Bright-switching
• Voltage drop
  ≤ 2 V
• Symbol
  00991638
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Working range
  0 mm ... 600 mm
• Short-circuit protection
  Pulsed
• Reverse polarity protection
  for all electrical connections
• Size
  M18x1
• Material of union nut
  Brass Chrome-plated
• Type code
  SOEG
• Measured variable
  Position
• Method of measurement
  Reflection light sensor
• Max. switching frequency
  1000 Hz
• Residual ripple
  20 %
• Product weight
  123 g
• Ambient temperature with flexible cable installation
  -5 °C ... 55 °C
Type of light
Red
Max. output current
200 mA
DC operating voltage range
10 V ... 36 V
Type of mounting
With lock nut
Housing material
Brass Chrome-plated
Setting options
Potentiometer
Degree of protection
IP65 IP67
Design
Round
Note on materials
Free of copper and PTFE
Switching output
PNP
Idle current
15 mA
Material of cable sheath
TPE-U(PUR)
Function reserve indication
LED green
Corrosion resistance class (CRC)
1 - Low corrosion stress
Electrical connection
3-wire Cable
Cable length
2.5 m
Tightening torque
20 Nm
Setting range, lower limit
100 mm
Switching status indication
LED yellow
Setting range, upper limit
600 mm
