193406 Festo Pneumatic Tubing

193406 on Powermatic Associates
Festo

Part#:193406

Alt. Part#:PLN-10X1,5-NT

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

plastic tubing PLN-10X1,5-NT highly resistant to chemicals and hydrolysis. Outside diameter: 10 mm, Bending radius relevant for flow rate: 57 mm, Inside diameter: 7 mm, Min. bending radius: 22 mm, Temperature dependent operating pressure: -0,95 - 14 bar

Product Details

  • Inside diameter
    7 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Material of pneumatic tubing
    PE
  • Min. bending radius
    22 mm
  • Product weight by length
    0.0375 kg/m
  • Certificate issuing authority
    B 013277 0506 00
  • For use in the food industry
    See supplementary material information
  • Outside diameter
    10 mm
  • Type code
    PLN
  • Ambient temperature
    -30 °C ... 80 °C
  • Pneumatic connection
    For plug connection outside diameter 10 mm
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Bending radius relevant for flow rate
    57 mm
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Certification
    German Technical Control Board (TÜV)
  • Color
    Natural

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
