159665 Festo Pneumatic Tubing

Product Details

• Bending radius relevant for flow rate
  26.5 mm
• Tubing characteristics
  Suitable for energy chains in applications with high cycle rates
• Inside diameter
  4 mm
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:-:-]
• Pneumatic connection
  For plug connection outside diameter 6 mm For barbed fitting, inside diameter 4 mm
• Material of pneumatic tubing
  TPE-U(PU)
• Outside diameter
  6 mm
• Min. bending radius
  16 mm
• Certificate issuing authority
  B 013277 0506 00
• Shore hardness
  D 52 +/-3
• Pneumatic tubing test conditions
  Suitability for energy chains: >5 million cycles as per FN 942021
• Type code
  PUN
• Material fire test
  UL94 HB
• Color
  Black
• Certification
  German Technical Control Board (TÜV)
• Note on materials
  Free of copper and PTFE RoHS-compliant
• Temperature-dependent operating pressure
  -0.95 bar ... 10 bar
• Product weight by length
  0.0192 kg/m
• Ambient temperature
  -35 °C ... 60 °C
