193147 Festo Stop Valves (non-return)
Part#:193147
Alt. Part#:GRLA-1/4-QS-8-D
Manufacturer:Festo
Category:Stop Valves (non-return)
Product Lifecycle:Active
Product description
one-way flow control valve GRLA-1/4-QS-8-D Valve function: One-way flow control function for exhaust air, Pneumatic connection, port 1: QS-8, Pneumatic connection, port 2: G1/4, Adjusting element: Slotted head screw, Mounting type: Threaded
Product Details
- Type code GRLA
- Adjusting element Slotted screw
- Mounting position Any
- Standard flow rate in flow control direction 6 -> 0 bar 720 l/min
- Temperature of medium -10 °C ... 60 °C
- Seals material NBR
- Swivel joint material Die-cast zinc Chromated
- Pneumatic connection 1 QS-8
- Pneumatic connection 2 G¼
- Operating pressure for entire temperature range 0.2 bar ... 10 bar
- Tolerance for nominal tightening torque ± 10%
- Maritime classification See certificate
- Type of mounting Screw-in
- Standard nominal flow rate in flow control direction 475 l/min
- Standard nominal flow rate in non-return direction 325 l/min ... 500 l/min
- Nominal tightening torque 5 Nm
- Product weight 42 g
- Symbol 00991452
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Material of screwed trunnion Wrought aluminum alloy
- Material of adjusting screw Brass
- Valve function Exhaust air flow control non-return function
- Ambient temperature -10 °C ... 60 °C
- Standard flow rate in non-return direction at 6 -> 0 bar 610 l/min ... 760 l/min
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Note on materials RoHS-compliant
- Releasing ring material POM
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
