177786 Festo Pneumatic Actuators
Part#:177786
Alt. Part#:DNC-11/4"-16"-P
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
profile cylinder DNC-11/4"-16"-P per ISO 15552, with profile cylinder barrel, non-adjustable cushioning. Stroke: 16 ", Piston diameter: 1 1/4", Piston rod thread: 3/8-24 UNF-2A, Based on the standard: ISO 15552 (previously also VDMA 24652, ISO 6431, NF E4
Product Details
- Design Piston Profile barrel
- Variants Piston rod at one end
- Impact energy in the end positions 0.1 J
- Type code DNC
- Piston rod thread 3/8-24 UNF-2A
- Piston rod end External thread
- Operating pressure 0.06 MPa ... 1.2 MPa
- Ambient temperature -20 °C ... 80 °C
- Additional moving mass per 10 mm stroke 9 g
- Piston diameter 1 1/4"
- Note on materials RoHS-compliant
- Piston rod material High-alloy steel
- Position sensing None
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Basic weight with 0 mm stroke 517 g
- Cover material Die-cast aluminum Coated
- Stroke 406.4 mm
- Based on norm ISO 15552 (previously also VDMA 24562, ISO 6431, NF E49 003.1, UNI 10290)
- Symbol 00991227
- Theoretical force at 6 bar, retracting 415 N
- Additional weight per 10 mm stroke 30 g
- Cushioning Elastic cushioning rings/pads at both ends
- Pneumatic connection NPT1/8-27
- Mode of operation Double-acting
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Seals material TPE-U(PU)
- Maritime classification See certificate
- Mounting position Any
- Material of cylinder barrel Wrought aluminum alloy Smooth anodized
- Moving mass at 0 mm stroke 162 g
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Type of mounting With internal thread With accessories
- Theoretical force at 6 bar, advancing 483 N
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
177786 Related Documents
Manufacturer warranty
177786 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 177786 with other products
Design
Variants
Impact energy in the end ...
Type code
Piston rod thread
Piston rod end
Operating pressure
Ambient temperature
Additional moving mass pe...
Piston diameter
Note on materials
Piston rod material
Position sensing
Operating medium
Basic weight with 0 mm st...
Cover material
Stroke
Based on norm
Symbol
Theoretical force at 6 ba...
Additional weight per 10 ...
Cushioning
Pneumatic connection
Mode of operation
Information on operating ...
Seals material
Maritime classification
Mounting position
Material of cylinder barr...
Moving mass at 0 mm strok...
Corrosion resistance clas...
Type of mounting
Theoretical force at 6 ba...
Conforms to standard
Piston seal material
Material of piston
Buffer seal material
Material of bearing
Piston rod wiper seal mat...
Nut material
Cushion piston material
Flange screws material
Cushioning length
Selected product
177786
Festo
profile cylinder DNC-11/4"-16"-P per ISO 15552, with profile cylinder barrel, non-adjustable cushion...
DesignPiston Profile barrel
VariantsPiston rod at one end
Impact energy in the end positions0.1 J
Type codeDNC
Piston rod thread3/8-24 UNF-2A
Piston rod endExternal thread
Operating pressure0.06 MPa ... 1.2 MPa
Ambient temperature-20 °C ... 80 °C
Additional moving mass per 10 mm stroke9 g
Piston diameter1 1/4"
Note on materialsRoHS-compliant
Piston rod materialHigh-alloy steel
Position sensingNone
Operating mediumCompressed air as per ISO 85...
Basic weight with 0 mm stroke517 g
Cover materialDie-cast aluminum Coated
Stroke406.4 mm
Based on normISO 15552 (previously also V...
Symbol00991227
Theoretical force at 6 bar, retracting415 N
Additional weight per 10 mm stroke30 g
CushioningElastic cushioning rings/pad...
Pneumatic connectionNPT1/8-27
Mode of operationDouble-acting
Information on operating and pilot mediaOperation with oil lubricati...
Seals materialTPE-U(PU)
Maritime classificationSee certificate
Mounting positionAny
Material of cylinder barrelWrought aluminum alloy Smoot...
Moving mass at 0 mm stroke162 g
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Type of mountingWith internal thread With ac...
Theoretical force at 6 bar, advancing483 N
Conforms to standard-
Piston seal material-
Material of piston-
Buffer seal material-
Material of bearing-
Piston rod wiper seal material-
Nut material-
Cushion piston material-
Flange screws material-
Cushioning length-
536287
Festo
compact cylinder ADN-32-80-I-P-A Per ISO 21287, with position sensing and internal piston rod thread...
Design-
VariantsPiston rod at one end
Impact energy in the end positions0.4 J
Type codeADN
Piston rod threadM8
Piston rod endInternal thread
Operating pressure0.6 bar ... 10 bar
Ambient temperature-20 °C ... 80 °C
Additional moving mass per 10 mm stroke9 g
Piston diameter32 mm
Note on materialsRoHS-compliant
Piston rod materialHigh-alloy steel
Position sensingFor proximity sensor
Operating mediumCompressed air as per ISO 85...
Basic weight with 0 mm stroke265 g
Cover materialAluminum Anodized
Stroke80 mm
Based on norm-
Symbol00991217
Theoretical force at 6 bar, retracting415 N
Additional weight per 10 mm stroke30 g
CushioningElastic cushioning rings/pad...
Pneumatic connectionG1/8
Mode of operationDouble-acting
Information on operating and pilot mediaOperation with oil lubricati...
Seals materialTPE-U(PUR)
Maritime classification-
Mounting positionAny
Material of cylinder barrelWrought aluminum alloy Smoot...
Moving mass at 0 mm stroke60 g
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Type of mountingOptionally: With accessories
Theoretical force at 6 bar, advancing483 N
Conforms to standardISO 21287
Piston seal material-
Material of piston-
Buffer seal material-
Material of bearing-
Piston rod wiper seal material-
Nut material-
Cushion piston material-
Flange screws material-
Cushioning length-
1804669
Festo
standards-based cylinder DSBC-125-250-PPSA-N3 with self-adjusting pneumatic end position cushioning ...
DesignPiston Profile barrel
VariantsPiston rod at one end
Impact energy in the end positions3.3 J
Type codeDSBC
Piston rod threadM27x2
Piston rod endExternal thread
Operating pressure0.02 MPa ... 1 MPa
Ambient temperature-20 °C ... 80 °C
Additional moving mass per 10 mm stroke63 g
Piston diameter125 mm
Note on materialsRoHS-compliant
Piston rod materialHigh-alloy steel
Position sensingFor proximity sensor
Operating mediumCompressed air as per ISO 85...
Basic weight with 0 mm stroke6611 g
Cover materialDie-cast aluminum, coated
Stroke250 mm
Based on norm-
Symbol00992970
Theoretical force at 6 bar, retracting6881 N
Additional weight per 10 mm stroke151 g
CushioningSelf-adjusting pneumatic end...
Pneumatic connectionG1/2
Mode of operationDouble-acting
Information on operating and pilot mediaOperation with oil lubricati...
Seals material-
Maritime classification-
Mounting positionAny
Material of cylinder barrelWrought aluminum alloy, smoo...
Moving mass at 0 mm stroke2245 g
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Type of mountingOptionally: With accessories
Theoretical force at 6 bar, advancing7363 N
Conforms to standardISO 15552
Piston seal materialTPE-U(PU)
Material of pistonWrought aluminum alloy
Buffer seal materialTPE-U(PU)
Material of bearingPOM
Piston rod wiper seal materialTPE-U(PU)
Nut materialSteel, galvanized
Cushion piston materialPOM
Flange screws materialSteel, galvanized
Cushioning length45 mm
