1691730 Festo Proportional Valves

Product Details

• Type code
  VPPL
• KC characters
  KC EMC
• Safety instructions
  VPPL safety position: if the power supply cable breaks, the outlet pressure will drop to 0 bar.
• Type of control
  Direct
• Inlet pressure 1
  0 bar ... 50 bar
• Max. electrical power consumption
  26.7 W
• Analog input signal range
  4 - 20 mA
• Product weight
  1100 g
• Electrical connection IN
  Plug, M12, 5-pin, A-coded
• Mounting position
  Any Preferably upright
• Symbol
  00995268
• Valve function
  3-way proportional pressure control valve closed
• C value
  0.8 l/sbar
• DC operating voltage range
  21.6 V ... 27.6 V
• Residual ripple
  10 %
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Degree of protection
  IP65
• Electrical connection, diagnostic interface
  Socket, M12, 5-pin, A-coded
• Pneumatic connection 2
  Flange
• Nominal width pressurization
  2.5 mm
Sealing principle
Soft
Reverse polarity protection
for all electrical connections
Pressure regulation range
0.4 bar ... 40 bar
Standard nominal flow rate
300 l/min
Setpoint/actual values
Current type 4–20 mA
Information on operating and pilot media
Operation with oil lubrication not possible
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Linearity error in ± % FS
1 %FS
Electrical connection OUT
Plug, M12, 5-pin, A-coded
Pneumatic connection 3
Flange
Actuation type
Electrical
Short-circuit protection
no
Operating pressure
≤ 50 bar
b-value
0.25
Switching time off
550 ms
Duty cycle
100%
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Ambient temperature
5 °C ... 50 °C
Repetition accuracy in ± %FS
1 %FS
Pneumatic connection 1
Flange
Housing material
Wrought aluminum alloy Anodized
Exhaust nominal width
2.5 mm
Design
Directly controlled piston regulator
Reset method
Mechanical spring
Display type
LED display
Max. pressure hysteresis
0.3 bar
On switching time
300 ms
Analog output signal range
4 - 20 mA
Temperature of medium
5 °C ... 50 °C
Temperature coefficient
0.04 %/K
Type of mounting
With through-hole
Note on materials
RoHS-compliant
