159577 Festo Compressed Air Preparation Units

159577 on Powermatic Associates
Festo

Part#:159577

Alt. Part#:LF-3/8-D-MIDI-A

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Product description

filter LF-3/8-D-MIDI-A With metal bowl guard. Size: Midi, Series: D, Assembly position: Vertical +/- 5°, Grade of filtration: 40 µm, Condensate drain: fully automatic

Product Details

  • Maritime classification
    See certificate
  • Mounting position
    Vertical +/- 5°
  • Bowl guard
    Metal bowl guard
  • Storage temperature
    -10 °C ... 60 °C
  • Product weight
    700 g
  • Compressed air filter material
    PE
  • Type code
    LF
  • Design
    Sinter filter with centrifugal separator
  • Standard nominal flow rate
    2700 l/min
  • Temperature of medium
    5 °C ... 60 °C
  • Pneumatic connection 2
    G3/8
  • Size
    Midi
  • Series
    D
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:9:-] Inert gas
  • Air quality class at the output
    Compressed air as per ISO 8573-1:2010 [7:8:4] Inert gas
  • Type of mounting
    Line installation With accessories
  • Condensate drain
    Fully automatic
  • Symbol
    00991520
  • Operating pressure
    2 bar ... 12 bar
  • Ambient temperature
    5 °C ... 60 °C
  • Note on materials
    RoHS-compliant
  • Grade of filtration
    40 µm
  • Max. condensate volume
    43 ml
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Pneumatic connection 1
    G3/8
  • Housing material
    Die-cast zinc
  • Material of bowl
    PC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
