156928 Festo Pneumatic Actuators

156928 on Powermatic Associates
Festo

Part#:156928

Alt. Part#:ADVUL-100-60-P-A

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Product description

compact cylinder ADVUL-100-60-P-A For proximity sensing. Piston rod secured against rotation by means of guide rod and yoke plate. Stroke: 60 mm, Piston diameter: 100 mm, Cushioning: P: Flexible cushioning rings/plates at both ends, Assembly position: Any

Product Details

  • Type code
    ADVUL
  • Design
    Piston Piston rod
  • Position sensing
    For proximity sensor
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Theoretical force at 6 bar, retracting
    4418 N
  • Pneumatic connection
    G1/4
  • Cushioning
    Elastic cushioning rings/pads at both ends
  • Variants
    Piston rod at one end
  • Mode of operation
    Double-acting
  • Type of mounting
    Optionally: With accessories
  • Stroke
    60 mm
  • Mounting position
    Any
  • Symbol
    00991737
  • Operating pressure
    1 bar ... 10 bar
  • Ambient temperature
    -20 °C ... 80 °C
  • Theoretical force at 6 bar, advancing
    4712 N
  • Flange screws material
    Steel, galvanized
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Piston rod material
    High-alloy steel
  • Material of dynamic seals
    NBR TPE-U(PU)
  • Piston diameter
    100 mm
  • Protection against torsion/guide
    Guide rod with yoke
  • Impact energy in the end positions
    1 J
  • Cover material
    Wrought aluminum alloy
  • Material of cylinder barrel
    Wrought aluminum alloy

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

156928 Related Documents

156928 DataSheet.pdf
