154200 Festo Proportional Valves

Product Details

• Actuation type
  Electrical
• Design
  Piston gate valve
• Type of control
  Direct
• C value
  0.45 l/sbar
• Max. hysteresis
  0.4 %
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Certification
  RCM compliance mark
• Electrical connection
  4-pin Round design
• Pneumatic connection 4
  M5
• Housing material
  Aluminum Anodized
• Nominal width
  2 mm
• Mounting position
  Any
• Safety instructions
  MPYE safety position: if the power supply cable breaks, the blocked mid-position is approached.
• Valve function
  5/3, closed
• DC operating voltage range
  17 V ... 30 V
• Ambient temperature
  0 °C ... 50 °C
• Pneumatic connection 1
  M5
• Note on materials
  RoHS-compliant
• Flow direction
  Non-reversible
• Operating pressure
  0 bar ... 10 bar
Setpoint/actual values
Voltage type 0 - 10 V
Degree of protection
IP65
Type of mounting
With through-hole
Pneumatic connection 2
M5
KC characters
KC EMC
Sealing principle
Hard
Symbol
00995308
b-value
0.21
Residual ripple
5 %
Operating medium
Compressed air as per ISO 8573-1:2010 [6:4:4]
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Product weight
255 g
Cover material
ABS Coated
Seals material
NBR
Type code
MPYE
Reset method
Magnetic spring
Reverse polarity protection
for all electrical connections
Standard nominal flow rate
100 l/min
Cut-off frequency
115 Hz
Information on operating and pilot media
Operation with oil lubrication not possible
Temperature of medium
5 °C ... 40 °C
Pneumatic connection 3
M5
Pneumatic connection 5
M5

Related documents 154200 Specs
