542578 Festo Compressed Air Preparation Units
Part#:542578
Alt. Part#:MS4-EE-1/4-10V24
Manufacturer:Festo
Category:Compressed Air Preparation Units
Product Lifecycle:Active
Mar 14, 2025
Product description
on-off valve MS4-EE-1/4-10V24 Electrical, direction of flow: from left to right. Design structure: Piston slide, Type of actuation: electrical, Exhaust-air function: not throttleable, Manual override: Pushing, Type of reset: mechanical spring
Product Details
- Type code MS4-EE
- Exhaust air function Without flow control option
- Type of control Pilot-controlled
- Valve function 3/2, closed, monostable
- Standard nominal flow rate 2000 l/min
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Ambient temperature -10 °C ... 50 °C
- Mounting position Any
- Pneumatic connection 3 G1/4
- Actuation type Electrical
- Coil characteristics 24 V DC: 1.8 W
- Degree of protection IP65
- Pneumatic connection 1 G1/4
- Seals material NBR
- Reset method Mechanical spring
- b-value 0.44
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
- Note on materials RoHS-compliant
- Flow direction Non-reversible
- Pilot air supply port Internal
- For use in the food industry See supplementary material information
- Manual override Non-detenting
- Operating pressure 4 bar ... 10 bar
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Temperature of medium -10 °C ... 50 °C
- Product weight 273 g
- Electrical connection Form C Rectangular design
- Design Piston gate valve
- Symbol 00991008
- C value 9.5 l/sbar
- Duty cycle 100%
- Type of mounting Optionally: With accessories
- Pneumatic connection 2 G¼
- Housing material Die-cast aluminum
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
542578 Related Documents
Manufacturer warranty
542578 Festo
Get a quick Quote!
Request a quote, and we will send you price within minutes.
Stock:
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 542578 with other products
Type code
Exhaust air function
Type of control
Valve function
Standard nominal flow rat...
Corrosion resistance clas...
Ambient temperature
Mounting position
Pneumatic connection 3
Actuation type
Coil characteristics
Degree of protection
Pneumatic connection 1
Seals material
Reset method
b-value
Operating medium
Note on materials
Flow direction
Pilot air supply port
For use in the food indus...
Manual override
Operating pressure
Information on operating ...
Temperature of medium
Product weight
Electrical connection
Design
Symbol
C value
Duty cycle
Type of mounting
Pneumatic connection 2
Housing material
Nominal width
Sealing principle
Switching time off
Storage temperature
On switching time
Vibration resistance
Noise level
Pilot exhaust air port 82...
Pneumatic connection 5
Width
Operating voltage
Certification
Pneumatic connection 4
Pilot pressure
Shock resistance
Lap
Pneumatic working port
Width dimension
Pilot medium
Max. negative test pulse ...
Max. positive test pulse ...
Pilot air port 12
Pilot exhaust air port 82
Selected product
542578
Festo
on-off valve MS4-EE-1/4-10V24 Electrical, direction of flow: from left to right. Design structure: P...
Type codeMS4-EE
Exhaust air functionWithout flow control option
Type of controlPilot-controlled
Valve function3/2, closed, monostable
Standard nominal flow rate2000 l/min
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Ambient temperature-10 °C ... 50 °C
Mounting positionAny
Pneumatic connection 3G1/4
Actuation typeElectrical
Coil characteristics24 V DC: 1.8 W
Degree of protectionIP65
Pneumatic connection 1G1/4
Seals materialNBR
Reset methodMechanical spring
b-value0.44
Operating mediumCompressed air as per ISO 85...
Note on materialsRoHS-compliant
Flow directionNon-reversible
Pilot air supply portInternal
For use in the food industrySee supplementary material i...
Manual overrideNon-detenting
Operating pressure4 bar ... 10 bar
Information on operating and pilot mediaOperation with oil lubricati...
Temperature of medium-10 °C ... 50 °C
Product weight273 g
Electrical connectionForm C Rectangular design
DesignPiston gate valve
Symbol00991008
C value9.5 l/sbar
Duty cycle100%
Type of mountingOptionally: With accessories
Pneumatic connection 2G¼
Housing materialDie-cast aluminum
Nominal width-
Sealing principle-
Switching time off-
Storage temperature-
On switching time-
Vibration resistance-
Noise level-
Pilot exhaust air port 82/84-
Pneumatic connection 5-
Width-
Operating voltage-
Certification-
Pneumatic connection 4-
Pilot pressure-
Shock resistance-
Lap-
Pneumatic working port-
Width dimension-
Pilot medium-
Max. negative test pulse on 1 signal-
Max. positive test pulse with 0 signal-
Pilot air port 12-
Pilot exhaust air port 82-
173127
Festo
solenoid valve MEH-5/2-1/8-B Midi Pneumatic, with solenoid coil and manual override, without socket....
Type codeMEH
Exhaust air functionWith flow control option
Type of controlPilot-controlled
Valve function5/2, monostable
Standard nominal flow rate600 l/min
Corrosion resistance class (CRC)2 - Moderate corrosion stres...
Ambient temperature-5 °C ... 50 °C
Mounting positionAny
Pneumatic connection 3G1/8
Actuation typeElectrical
Coil characteristics24 V DC: 1.5 W
Degree of protectionIP65
Pneumatic connection 1G1/8
Seals materialHNBR NBR
Reset methodMechanical spring
b-value0.36
Operating mediumCompressed air as per ISO 85...
Note on materialsRoHS-compliant
Flow directionNon-reversible
Pilot air supply portInternal
For use in the food industry-
Manual overrideDetenting via accessory
Operating pressure2.5 bar ... 8 bar
Information on operating and pilot mediaOperation with oil lubricati...
Temperature of medium-5 °C ... 50 °C
Product weight105 g
Electrical connectionConnection diagram form C as...
DesignPiston gate valve
Symbol00991035
C value2.55 l/sbar
Duty cycle100%
Type of mountingWith through-hole
Pneumatic connection 2G1/8
Housing materialDie-cast aluminum
Nominal width5 mm
Sealing principleSoft
Switching time off28 ms
Storage temperature-20 °C ... 40 °C
On switching time10 ms
Vibration resistanceTransport application test w...
Noise level75 dB(A)
Pilot exhaust air port 82/84M5
Pneumatic connection 5G1/8
Width17.8 mm
Operating voltage24V DC
Certificationc UL us - Recognized (OL)
Pneumatic connection 4G1/8
Pilot pressure2.5 bar ... 8 bar
Shock resistanceShock test with severity lev...
LapOverlap
Pneumatic working portG1/8
Width dimension18 mm
Pilot mediumCompressed air as per ISO 85...
Max. negative test pulse on 1 signal-
Max. positive test pulse with 0 signal-
Pilot air port 12-
Pilot exhaust air port 82-
7959
Festo
solenoid valve MFH-3-1/4-S With manual override, without solenoid coil or socket. Solenoid coil and ...
Type codeMFH
Exhaust air functionWith flow control option
Type of controlPilot-controlled
Valve function3/2, closed, monostable
Standard nominal flow rate800 l/min
Corrosion resistance class (CRC)1 - Low corrosion stress
Ambient temperature-5 °C ... 40 °C
Mounting positionAny
Pneumatic connection 3G1/4
Actuation typeElectrical
Coil characteristicsSee solenoid coil, to be ord...
Degree of protectionIP65
Pneumatic connection 1G1/4
Seals materialNBR
Reset methodMechanical spring
b-value-
Operating mediumCompressed air as per ISO 85...
Note on materialsRoHS-compliant
Flow directionReversible
Pilot air supply portExternal
For use in the food industry-
Manual overrideDetenting
Operating pressure-0.95 bar ... 10 bar
Information on operating and pilot mediaOperation with oil lubricati...
Temperature of medium-10 °C ... 60 °C
Product weight320 g
Electrical connectionVia F coil, to be ordered se...
DesignPlate seat
Symbol00992879
C value-
Duty cycle-
Type of mountingOptionally: With through-hol...
Pneumatic connection 2G¼
Housing materialDie-cast aluminum
Nominal width7 mm
Sealing principleSoft
Switching time off29 ms
Storage temperature-20 °C ... 60 °C
On switching time10 ms
Vibration resistance-
Noise level-
Pilot exhaust air port 82/84-
Pneumatic connection 5-
Width30.5 mm
Operating voltageVia solenoid coil, to be ord...
Certificationc UL us - Recognized (OL)
Pneumatic connection 4-
Pilot pressure1 bar ... 8 bar
Shock resistance-
LapUnderlap
Pneumatic working portG1/4
Width dimension32 mm
Pilot mediumCompressed air as per ISO 85...
Max. negative test pulse on 1 signal3700 µs
Max. positive test pulse with 0 signal2200 µs
Pilot air port 12M5
Pilot exhaust air port 82M5
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to electric drives and complete automation systems, Festo ensures that industries can achieve seamless operations and enhanced productivity. As specialists in motion and control technologies, Powermatic Associates supplies Festo's advanced pneumatics and electromechanical systems, designed to meet the rigorous demands of modern manufacturing environments. Festo's pneumatic cylinders and actuators are engineered for precision and reliability, providing optimal performance in a variety of applications, from simple handling tasks to complex automation processes. Festo's cutting-edge sensors and control units further complement these systems by delivering accurate data and enabling sophisticated process control, which are essential for smart factory initiatives. Moreover, Festo excels in modular automation solutions, allowing businesses to customize systems tailored specifically to their operational needs. Their energy-efficient pneumatic components and electric automation solutions are designed to reduce energy consumption and contribute to sustainable manufacturing practices. By integrating Festo’s products into their facilities, customers can streamline production processes, minimize downtime, and elevate overall operational efficiency. Powermatic Associates complements Festo's product range with our extensive value-added services, including expert engineering support and customized automation solutions. Our partnership with Festo allows us to provide superior technical assistance and rapid delivery from our well-stocked inventory. Whether you need precise fluid control, reliable actuation, or comprehensive system integration, Powermatic Associates and Festo together offer unparalleled service and solutions. Trust in our collaboration to harness the latest advancements in automation technology, ensuring your projects remain on track and your business achieves maximum profitability. Through this strategic partnership, Powermatic Associates and Festo empower industries to embrace innovation and maintain a competitive edge in the fast-evolving industrial landscape, driving forward efficiency, productivity, and sustainability.
About the Product Category
Also referred to as an FRL unit (Filter, Regulator, Lubricator), an air preparation unit is utilized to treat compressed air. It accomplishes this by eliminating impurities, managing pressure, and adding specific quantities of oil for lubrication.
