541282 Festo Compressed Air Preparation Units

541282 on Powermatic Associates
Festo

Part#:541282

Alt. Part#:MS4N-EM1-1/4-S-Z

Manufacturer:Festo

Category:Compressed Air Preparation Units

Product Lifecycle:Active

Only 2 left in stock. Order Now!

Apr 9, 2025

Product description

on-off valve MS4N-EM1-1/4-S-Z Manual, with silencer, direction of flow: from right to left. Design structure: Rotary slide valve, Type of actuation: manual, Exhaust-air function: not throttleable, Type of piloting: direct, Valve function: 3/2 bistable

Product Details

  • Design
    Rotary gate valve
  • Valve function
    3/2, bistable
  • Standard nominal flow rate
    2200 l/min
  • Temperature of medium
    -10 °C ... 60 °C
  • Product weight
    210 g
  • Housing material
    Die-cast aluminum
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
  • Type of mounting
    Optionally: With accessories
  • Flow direction
    Non-reversible
  • Pneumatic connection 2
    1/4 NPT
  • For use in the food industry
    See supplementary material information
  • Type code
    MS4N-EM1
  • Type of control
    Direct
  • b-value
    0.39
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Pneumatic connection 1
    1/4 NPT
  • Actuation type
    Manual
  • Symbol
    00991670
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Mounting position
    Any
  • Seals material
    TPE-U(PU)
  • Exhaust air function
    Without flow control option
  • Operating pressure
    0 bar ... 14 bar
  • C value
    9 l/sbar
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 3
    Not ducted

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
