152824 Festo Pneumatic Tubing

152824 on Powermatic Associates
Festo

Part#:152824

Alt. Part#:PUN-8X1,25-DUO-SI

Manufacturer:Festo

Category:Pneumatic Tubing

Product Lifecycle:Active

Product description

DUO tubing PUN-8X1,25-DUO-SI Standard O.D tubing, for QS plug connectors, CN and CK polyurethane fittings (not approved for use in the food industry). Outside diameter: 8 mm, Bending radius relevant for flow rate: 37 mm, Inside diameter: 5,7 mm, Min. bend

Product Details

  • Min. bending radius
    24 mm
  • Certificate issuing authority
    B 013277 0506 00
  • Certification
    German Technical Control Board (TÜV)
  • Shore hardness
    D 52 +/-3
  • Bending radius relevant for flow rate
    37 mm
  • Pneumatic connection
    For plug connection outside diameter 8 mm For barbed fitting, inside diameter 6 mm
  • Material of pneumatic tubing
    TPE-U(PU)
  • Outside diameter
    8 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Color
    Silver
  • Pneumatic tubing test conditions
    Suitability for energy chains: >5 million cycles as per FN 942021
  • Inside diameter
    5.7 mm
  • Type code
    PUN-DUO
  • Tubing characteristics
    Suitable for energy chains in applications with high cycle rates
  • Temperature-dependent operating pressure
    -0.95 bar ... 10 bar
  • Ambient temperature
    -35 °C ... 60 °C
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Material fire test
    UL94 HB
  • Product weight by length
    0.0604 kg/m

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

152824 Related Documents

152824 DataSheet.pdf
