152648 Festo Position Sensors

152648 on Powermatic Associates
Festo

Part#:152648

Alt. Part#:MLO-POT-450-LWG

Manufacturer:Festo

Category:Position Sensors

Product Lifecycle:Active

Product description

displacement encoder MLO-POT-450-LWG With absolute displacement encoder, 450 mm effective electrical displacement, for axis controller type SPC-100 CE mark (see declaration of conformity): to EU directive for EMC, Measuring method: displacement encoder: A

Product Details

  • Type code
    MLO
  • Recommended contact current
    < 1 µA
  • Displacement resolution
    0.01 mm
  • Electrical connection
    16 mm Rectangular design
  • Mounting position
    Any
  • Material of connecting rod
    High-alloy stainless steel
  • Degree of protection
    IP65 as per IEC 60529
  • Max. travel acceleration
    200 m/s²
  • Stroke
    450 mm
  • Nominal operating voltage DC
    10 V
  • Permissible voltage fluctuations
    < 1 %
  • Cover material
    PBT-reinforced
  • Material of rod seal
    PTFE
  • Ambient temperature
    -30 °C ... 100 °C
  • Temperature coefficient
    5 ppm/K
  • Connection resistance tolerance
    20 %
  • Max. current consumption
    4 mA
  • Housing material
    Wrought aluminum alloy Anodized
  • Material of bearing seal
    NBR
  • Continuous shock resistance to DIN/IEC 68 Part 2-82
    Tested as per severity level 2
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Max. short-time slider current
    10000 µA
  • Independent linearity
    0.05 %
  • Connection resistance
    5 kOhm
  • Design
    Round profile with connecting rod
  • Measuring principle of linear potentiometer
    Analog
  • Max. travel speed
    5 m/s
  • Output signal
    Analog
  • Max. operating voltage DC
    42 V
  • Moment compensator angular offset
    ± 12.5 °
  • Product weight
    900 g
  • Vibration resistance to DIN/IEC 68 Part 2-6
    Tested as per severity level 2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
