152629 Festo Position Sensors

152629 on Powermatic Associates
Festo

Part#:152629

Alt. Part#:MLO-POT-500-TLF

Manufacturer:Festo

Category:Position Sensors

Product Lifecycle:Active

Product description

displacement encoder MLO-POT-500-TLF CE mark (see declaration of conformity): to EU directive for EMC, Measuring method: displacement encoder: Analogue, Ambient temperature: -30 - 100 °C, Recommended wiper current: < 1 µA, Max. intermittent wiper current:

Product Details

  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Max. travel speed
    10 m/s
  • Stroke
    500 mm
  • Output signal
    Analog
  • Mounting position
    Any
  • Covering material
    Steel
  • Slide carriage housing material
    Die-cast aluminum Polymer
  • Continuous shock resistance to DIN/IEC 68 Part 2-82
    Tested as per severity level 2
  • Recommended contact current
    < 1 µA
  • Nominal operating voltage DC
    10 V
  • Design
    with cover strip Open profile
  • Moment compensator angular offset
    ± 1 °
  • Material of assembly brackets
    PEI
  • Type code
    MLO
  • Max. short-time slider current
    10000 µA
  • Temperature coefficient
    5 ppm/K
  • Connection resistance tolerance
    20 %
  • Electrical connection
    4-pin Rectangular design
  • Permissible voltage fluctuations
    < 1 %
  • Housing material
    Wrought aluminum alloy Anodized
  • Degree of protection at top
    as per IEC 60529
  • Ambient temperature
    -30 °C ... 100 °C
  • Independent linearity
    0.05 %
  • Connection resistance
    5 kOhm
  • Max. current consumption
    4 mA
  • Product weight
    1300 g
  • Cover material
    Polymer
  • Vibration resistance to DIN/IEC 68 Part 2-6
    Tested as per severity level 2
  • Measuring principle of linear potentiometer
    Analog
  • Max. travel acceleration
    200 m/s²
  • Displacement resolution
    0.01 mm
  • Max. operating voltage DC
    42 V
  • Coupling parallel quick coupling
    ± 1.5 mm
  • Slide carriage coupling material
    Steel
  • Bottom degree of protection
    as per IEC 60529

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
