1470777 Festo Electric Actuators

Product Details

• Stroke reserve
  0 mm
• Reversing backlash
  100 µm
• Step angle tolerance
  ±5%
• Protection against torsion/guide
  With plain-bearing guide
• Max. speed
  0.5 m/s
• Motor nominal current
  3 A
• Certification
  RCM compliance mark c UL us - Recognized (OL)
• Max. torque Mz
  1 Nm
• Guide value for payload, horizontal
  20 kg
• Screw diameter
  10 mm
• Motor type
  Stepper motor
• Spindle type
  Ball screw drive
• Nominal operating voltage DC
  24 V
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Degree of protection
  IP40
• Mass moment of inertia JH per meter of stroke
  0.0578 kgcm²
• Mass moment of inertia JO
  0.094 kgcm²
• Type of mounting
  With internal thread With accessories
• Spindle material
  Roller bearing steel
• Size
  25
Piston rod thread
M8
Spindle pitch
10 mm/U
Type code
EPCO
Design
Electric actuator with ball screw drive
Rotor position sensor
Incremental encoder
Max. acceleration
10 m/s²
Insulation protection class
B
Ambient temperature
0 °C ... 50 °C
Guide value for payload, vertical
10 kg
Moving mass at 0 mm stroke
145 g
Additional moving mass per 10 mm stroke
2.6 g
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
Stroke
300 mm
Step angle with full step
1.8 deg
Mounting position
Any
Rotor position sensor measuring principle
Optical
Repetition accuracy
±0.02 mm
Storage temperature
-20 °C ... 60 °C
Corrosion resistance class (CRC)
1 - Low corrosion stress
Max. torque My
1 Nm
Max. feed force Fx
105 N
Mass moment of inertia JL per kg of payload
0.0254 kgcm²
Cover material
Wrought aluminum alloy Smooth anodized
Max. angle of rotation of the piston rod +/-
1.5 deg
Piston rod end
External thread
Rotor position sensor interface
RS422 TTL A/B channels + zero index
Duty cycle
100%
Relative air humidity
0 - 85 % Non-condensing
Impact energy in the end positions
2.0E-4 J
Max. torque Mx
0 Nm
Additional weight per 10 mm stroke
34 g
Electrical connection technology
Plug
Housing material
Wrought aluminum alloy Smooth anodized
Basic weight with 0 mm stroke
1125 g
Spindle nut material
Steel
Piston rod material
High-alloy stainless steel
Material of cylinder barrel
Wrought aluminum alloy Smooth anodized
