574093 Festo Electric Actuators

Product Details

• Reversing backlash
  30 µm
• Piston rod end
  External thread
• Protection against torsion/guide
  With plain-bearing guide
• Degree of protection
  IP40
• Max. feed force Fx
  7000 N
• Mass moment of inertia JL per kg of payload
  0.00633 kgcm²
• Basic weight with 0 mm stroke
  3163 g
• Piston rod material
  High-alloy stainless steel
• Stroke
  100 mm
• Screw diameter
  25 mm
• Mounting position
  Any
• Spindle type
  Ball screw
• Duty cycle
  100%
• For use in the food industry
  See supplementary material information
• Relative air humidity
  0 - 95 %
• Guide value for payload, horizontal
  700 kg
• Moving mass at 0 mm stroke
  1829 g
• Type of mounting
  With internal thread or accessory
• Material of screws
  Steel, galvanized
• Size
  63
Piston rod thread
M16x1.5
Max. angle of rotation of the piston rod +/-
0.4 deg
Type code
ESBF
Position sensing
For proximity sensor
Max. acceleration
5 m/s²
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Ambient temperature
0 °C ... 60 °C
Guide value for payload, vertical
700 kg
Mass moment of inertia JO
0.49112 kgcm²
Cover material
Die-cast aluminum, coated
Spindle nut material
Roller bearing steel
Spindle pitch
5 mm/U
Motor type
Servo motor
Symbol
00991941
Max. speed
0.27 m/s
Max. driving torque
7 Nm
No-load driving torque
0.4 Nm
Additional weight per 10 mm stroke
87 g
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
Material of cylinder barrel
Wrought aluminum alloy, smooth-anodized
Based on norm
ISO 15552
Design
Electric actuator with ball screw
Repetition accuracy
±0.015 mm
Storage temperature
-20 °C ... 60 °C
Max. radial force on actuator shaft
700 N
Mass moment of inertia JH per meter of stroke
2.8316 kgcm²
Additional moving mass per 10 mm stroke
52 g
Interface code, actuator
D60
Spindle material
Roller bearing steel
