14015 Festo Vacuum Generators

14015 on Powermatic Associates
Festo

Part#:14015

Alt. Part#:VAD-1/8

Manufacturer:Festo

Category:Vacuum Generators

Product Lifecycle:Active

Product description

vacuum generator VAD-1/8 Nominal size, Laval nozzle: 0,8 mm, Assembly position: Any, Ejector characteristic: High vacuum, Design structure: T-shaped, Operating pressure: 1,5 - 10 bar

Product Details

  • Design
    T-shape
  • Ejector characteristics
    High vacuum
  • Max. vacuum
    80 %
  • Type of mounting
    With through-hole
  • Housing material
    Die-cast aluminum
  • Mounting position
    Any
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Ambient temperature
    -20 °C ... 80 °C
  • Vacuum connection
    G1/8
  • Nominal width of Laval nozzle
    0.8 mm
  • Symbol
    00991482
  • Pneumatic connection 1
    G1/8
  • Note on materials
    Free of copper and PTFE
  • Type code
    VAD
  • Operating pressure
    1.5 bar ... 10 bar
  • Temperature of medium
    -20 °C ... 80 °C
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Pneumatic connection 3
    G1/8

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
