526105 Festo Vacuum Generators

Product Details

• Nominal width of Laval nozzle
  0.7 mm
• Mounting position
  Any
• Muffler construction type
  Open
• Design
  T-shape
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Max. tightening torque
  0.5 Nm
• Seals material
  NBR
• Material of jet nozzle
  Wrought aluminum alloy
• Type code
  VN
• Integrated function
  Pneumatic muffler open
• Symbol
  00991489
• Max. suction rate with respect to atmosphere
  16 l/min
• Information on operating and pilot media
  Operation with oil lubrication not possible
• Ambient temperature
  0 °C ... 60 °C
• Vacuum connection
  M5
• Housing material
  POM-reinforced
• Width dimension
  10 mm
• Ejector characteristics
  High vacuum Standard
• Max. vacuum
  88 %
• Corrosion resistance class (CRC)
  1 - Low corrosion stress
Pneumatic connection 3
Pneumatic muffler open
Note on materials
Free of copper and PTFE RoHS-compliant
Operating pressure
1 bar ... 8 bar
Nominal operating pressure
6 bar
Noise level at nominal operating pressure
64 dB(A)
Pneumatic connection 1
M5
Material of connecting thread
Wrought aluminum alloy, anodized
Operating pressure for max. suction rate
2.1 bar
Operating pressure for max. vacuum
4.7 bar
Air supply time at nominal operating pressure
1.9 s
Temperature of medium
0 °C ... 60 °C
Type of mounting
With through-hole With accessories
Product weight
13 g
Female nozzle material
POM
Muffler material
PE
